Toyota WISH — DISC WHEEL & WHEEL CAP
42601WHEEL, DISC
15X6JJ, #,TYPE E:REFER ILLUST.
15X6JJ, #,TYPE E:REFER ILLUST.
17X7JJ,OFFSET 45, #,TYPE D:REFER ILLUST.
17X7JJ, #,TYPE F:REFER ILLUST.
15X6JJ, #,TYPE E:REFER ILLUST.
17X7J, #,TYPE F:REFER ILLUST.
17X7JJ,OFFSET 45, #,TYPE D:REFER ILLUST.
42601AWHEEL, DISC (FOR SPARE)
16X4T,TYPE C:REFER ILLUST.
16X4T,TYPE A:REFER ILLUST.
15X6JJ,TYPE C:REFER ILLUST.
42601CNUT, HUB (FOR AXLE)
TYPE C:REFER ILLUST.
TYPE A:REFER ILLUST.
TYPE D:REFER ILLUST.
42611GVALVE (FOR TUBELESS TIRE)
42611JVALVE (FOR TUBELESS TIRE SPARE)
42652TIRE
215/50R17,*B/S
195/65R15,*B/S
195/65R15,*B/S
215/50R17,*B/S
42652ATIRE (FOR SPARE)
T145/80D16,*B/S
195/65R15,*B/S
7 parts on this diagram · 4 diagrams in section
