Toyota VITZ GRMN — BACK DOOR LOCK & HANDLE
68801AHINGE SUB-ASSY, BACK DOOR, UPPER
68838PAD, BACK DOOR HINGE, NO.1
68945BRACKET, BACK DOOR DAMPER STAY, UPPER RH
68946BRACKET, BACK DOOR DAMPER STAY, UPPER LH
68947BRACKET, BACK DOOR DAMPER STAY, LOWER RH
68948BRACKET, BACK DOOR DAMPER STAY, LOWER LH
68950CSTAY ASSY, BACK DOOR, RH
68960STAY ASSY, BACK DOOR, LH
69350PLOCK ASSY, BACK DOOR, W/COURTESY LAMP SWITCH
69430CSTRIKER ASSY, BACK DOOR LOCK
9010506184
main90105-06184
90105W0030
main90105-W0030
90119W0129
main90119-W0129
90148W0004
main90148-W0004
9017908096
main90179-08096
15 parts on this diagram · 1 diagram in section
BACK DOOR LOCK & HANDLE for Toyota VITZ GRMN
This section contains 15 genuine Toyota parts for the BACK DOOR LOCK & HANDLE system of the Toyota VITZ GRMN. Key components include: HINGE SUB-ASSY, BACK DOOR, UPPER, PAD, BACK DOOR HINGE, NO.1, BRACKET, BACK DOOR DAMPER STAY, UPPER RH, BRACKET, BACK DOOR DAMPER STAY, UPPER LH, BRACKET, BACK DOOR DAMPER STAY, LOWER RH.
