Toyota TERCEL — CAUTION PLATE & NAME PLATE (ENGINE)

11292PLATE, ENGINE NAME, NO.2

main11292-11030i198808-199009

main11292-11050i198908-199009

11293APLATE, ENGINE CAUTION

main11293-74060i198808-198908

main17791-35080i198908-199009

11298PLATE, EMISSION CONTROL INFORMATION

main11298-11042i198808-198908

main11298-11043i198908-199009

main11298-11052i198808-198908

CALIFORNIA SPEC

main11298-11053i198908-199009

CALIFORNIA SPEC

main11298-11100i198908-199009

17792PLATE, ENGINE VACUUM HOSE INFORMATION

main17792-11142i198808-198904

main17792-11143i198904-198912

main17792-11144i198912-199009

main17792-11152i198808-198912

CALIFORNIA SPEC

main17792-11153i198912-199009

CALIFOLNIA SPEC

main17792-11172i198808-198912

CALIFORNIA & W(POWER STEERING)

main17792-11173i198912-199009

CALIFOLNIA SPEC & W(POWER STEERING)

main17792-11182i198808-198904

CALIFORNIA SPEC

main17792-11183i198904-198908

CALIFOLNIA SPEC

main17792-11192i198808-198904

CALIFORNIA & W(POWER STEERING)

main17792-11193i198904-198908

CALIFOLNIA SPEC & W(POWER STEERING)

main17792-11202i198808-198912

CALIFORNIA SPEC

main17792-11203i198912-199009

CALIFOLNIA SPEC

main17792-11330i198908-199009

W(POWER STEERING)

main17792-11350i198908-199009

4 parts on this diagram · 1 diagram in section

CAUTION PLATE & NAME PLATE (ENGINE) for Toyota TERCEL

This section contains 4 genuine Toyota parts for the CAUTION PLATE & NAME PLATE (ENGINE) system of the Toyota TERCEL. Key components include: PLATE, ENGINE NAME, NO.2, PLATE, ENGINE CAUTION, PLATE, EMISSION CONTROL INFORMATION, PLATE, ENGINE VACUUM HOSE INFORMATION.
