Toyota STARLET — CAUTION PLATE & NAME PLATE (ENGINE)

11291PLATE, ENGINE NAME

main11291-12010i197802-198409

main11291-13030i198108-198409

4K-C

main11291-13050i198108-198409

main11291-24040i197810-198208

3K-H

main11291-24080i197807-198108

3K-C

11297PLATE, ENGINE CAUTION, NO.3

main11297-13020i198001-198208

11298PLATE, EMISSION CONTROL INFORMATION

main11298-13100i198108-198208

main11298-13140i198208-198408

main11298-13141i198408-198409

main11298-13150i198208-198310

SWITZERLAND SPEC

main11298-13151i198310-198409

SWITZERLAND SPEC

main11298-24010i197807-198005

main11298-24012i198005-198108

16793PLATE, FAN CAUTION

main16793-13010i198208-198409

17700DPLATE, ENGINE CAUTION

main11293-13081i198101-198108

main11293-13082i198108-198208

main11293-13160i198208-198311

main11293-13161i198311-198409

main11293-24110i197802-197809

main11293-24111i197809-198101

17739PLATE, AIR CLEANER PART NUMBER

main17739-24010i197802-198008

ENGLAND SPEC

main17739-24030i197810-198008

ENGLAND SPEC

17792PLATE, ENGINE VACUUM HOSE INFORMATION

main17792-13230i198108-198409

main17792-13240i198108-198208

main17792-13290i198208-198409

7 parts on this diagram · 1 diagram in section

CAUTION PLATE & NAME PLATE (ENGINE) for Toyota STARLET

This section contains 7 genuine Toyota parts for the CAUTION PLATE & NAME PLATE (ENGINE) system of the Toyota STARLET. Key components include: PLATE, ENGINE NAME, PLATE, ENGINE CAUTION, NO.3, PLATE, EMISSION CONTROL INFORMATION, PLATE, FAN CAUTION, PLATE, ENGINE CAUTION.
