Toyota SOLARA — BACK UP LAMP

81670LAMP ASSY, BACK-UP, RH

main81670-06140i200605-200812

81670BBULB(FOR BACK-UP LAMP)

main90981-11059×2i200605-200808

12V 16W

81675SOCKET & WIRE, BACK-UP LAMP

main81585-06140×2i200605-200808

81680LAMP ASSY, BACK UP, LH

main81680-06140i200605-200812

90178A0005

main90178-A0005

5 parts on this diagram · 1 diagram in section

BACK UP LAMP for Toyota SOLARA

This section contains 5 genuine Toyota parts for the BACK UP LAMP system of the Toyota SOLARA. Key components include: LAMP ASSY, BACK-UP, RH, BULB(FOR BACK-UP LAMP), SOCKET & WIRE, BACK-UP LAMP, LAMP ASSY, BACK UP, LH.
