Toyota RAV4 PHV — WINDSHIELD WASHER

85035NOZZLE SUB-ASSY, WASHER

main85381-30220i202006-202310

main85381-30230i202006-202310

main85381-30240i202006-202310

8504REAR WASHER

→ Go to FIG 85-04

85301INLET SUB-ASSY, WASHER

main85301-42041i202006-202310

85301BCLIP, WASHER

main90467-07215i202006-202310

85310MOTOR AND PUMP ASSY, WINDSHIELD WASHER

main85330-47100i202006-202310

85330JAR ASSY, WINDSHIELD WASHER

main85315-42520i202006-202310

85330ABUSH, WINDSHIELD WASHER JAR

main90099-32089i202006-202310

85332CAP, WINDSHIELD WASHER JAR

main85316-42031i202006-202310

85336EPACKING, WINDSHIELD WASHER INLET HOSE

main85336-30160i202006-202310

85348JOINT, WINDSHIELD WASHER HOSE, NO.1

main85349-89122i202006-202310

85348GJOINT, WINDSHIELD WASHER HOSE, NO.2

main85375-10260i202006-202310

85355VALVE, WINDSHIELD WASHER HOSE

main85321-28020i202006-202310

85369CLAMP

main82711-16790i202006-202310

85371HOSE, WINDSHIELD WASHER (FROM MOTOR TO JOINT)

main90099-33080i202006-202310

85371ZCLAMP, WASHER HOSE

main90469-07011i202006-202310

85372HOSE, WINDSHIELD WASHER (FROM JOINT TO JOINT), NO.1

main90099-33803i202006-202310

85372BHOSE, WINDSHIELD WASHER (FROM JOINT TO JOINT), NO.2

main90099-33080i202006-202310

85373HOSE, WINDSHIELD WASHER (FROM JOINT TO NOZZLE)

main90099-33080i202006-202310

85387CLAMP NO.1 (FOR WINDSEIELD WASHER)

main82711-35520i202006-202310

85387ACLAMP, WASHER, NO.2

main85371-12040i202006-202310

85387BCLAMP, WASHER, NO.3

main85371-12040i202006-202310

85388CLAMP NO.2 (FOR WINDSEIELD WASHER)

main85387-42280i202006-202310

9011906767

main90119-06767

23 parts on this diagram · 1 diagram in section

WINDSHIELD WASHER for Toyota RAV4 PHV

This section contains 23 genuine Toyota parts for the WINDSHIELD WASHER system of the Toyota RAV4 PHV. Key components include: NOZZLE SUB-ASSY, WASHER, REAR WASHER, INLET SUB-ASSY, WASHER, CLIP, WASHER, MOTOR AND PUMP ASSY, WINDSHIELD WASHER.
