Toyota RAIZE — BACK DOOR LOCK & HANDLE
68801HINGE SUB-ASSY, BACK DOOR, UPPER RH
68802HINGE SUB-ASSY, BACK DOOR, UPPER LH
68945BRACKET, BACK DOOR DAMPER STAY, UPPER RH
68946BRACKET, BACK DOOR DAMPER STAY, UPPER LH
68947BRACKET, BACK DOOR DAMPER STAY, LOWER RH
68948BRACKET, BACK DOOR DAMPER STAY, LOWER LH
68950CSTAY ASSY, BACK DOOR, RH
68960STAY ASSY, BACK DOOR, LH
69350LOCK ASSY, BACK DOOR
69430CSTRIKER ASSY, BACK DOOR LOCK
9004105435
main90041-05435
9004105507
main90041-05507
9004105533
main90041-05533
9004182002
main90041-82002
9010506184
main90105-06184
9155180612
main91551-80612
16 parts on this diagram · 3 diagrams in section
BACK DOOR LOCK & HANDLE for Toyota RAIZE
This section contains 19 genuine Toyota parts for the BACK DOOR LOCK & HANDLE system of the Toyota RAIZE. Key components include: HINGE SUB-ASSY, BACK DOOR, UPPER RH, HINGE SUB-ASSY, BACK DOOR, RH, HINGE SUB-ASSY, BACK DOOR, UPPER LH, HINGE SUB-ASSY, BACK DOOR, LH, PAD, BACK DOOR HINGE, NO.1.
