Toyota RACTIS — BACK DOOR LOCK & HANDLE
67908STRAP SUB-ASSY, BACK DOOR PULL
BLACK,TRIM2#; BLACK,TRIM2#,4#
68810CHINGE ASSY, BACK DOOR, RH
68820CHINGE ASSY, BACK DOOR, LH
68838PAD, BACK DOOR HINGE, NO.1
68945BRACKET, BACK DOOR DAMPER STAY, UPPER RH
68946BRACKET, BACK DOOR DAMPER STAY, UPPER LH
68950CSTAY ASSY, BACK DOOR, RH
68960STAY ASSY, BACK DOOR, LH
68961BOLT, BACK DOOR STAY
69350PLOCK ASSY, BACK DOOR, W/COURTESY LAMP SWITCH
69430CSTRIKER ASSY, BACK DOOR LOCK
8401SWITCH & RELAY & COMPUTER
6796452010
main67964-52010
9010506184
main90105-06184
9011906748
main90119-06748
9014880066
main90148-80066
9015950353
main90159-50353
9017908096
main90179-08096
91651B0820
main91651-B0820
19 parts on this diagram · 1 diagram in section
BACK DOOR LOCK & HANDLE for Toyota RACTIS
This section contains 19 genuine Toyota parts for the BACK DOOR LOCK & HANDLE system of the Toyota RACTIS. Key components include: STRAP SUB-ASSY, BACK DOOR PULL, HINGE ASSY, BACK DOOR, RH, HINGE ASSY, BACK DOOR, LH, PAD, BACK DOOR HINGE, NO.1, BRACKET, BACK DOOR DAMPER STAY, UPPER RH.
