Toyota PROGRES — DISC WHEEL & WHEEL CAP

0001 1 0002 1

42601WHEEL, DISC

main42611-51010×4iJCG1#199805-200104

main42611-51020×4iJCG10,11199905-200104

main42611-51040×4iJCG1#200104

main42611-51050×4iJCG10,11200104

42601AWHEEL, DISC (FOR SPARE)

main42611-28210iJCG1#200104

sub42611-28211

main42611-51010iJCG1#199805-200104

main42611-51020iJCG10,11199905-200104

main42611-51040iJCG1#200104-200404

main42611-51050iJCG10,11200104-200404

42601CNUT, HUB (FOR AXLE)

main90942-01062×20iJCG1#199805-200104

42603ORNAMENT SUB-ASSY, WHEEL HUB

main42603-51010×4iJCG1#199805-200104

main42603-51020×4iJCG10,11199905-200104

main42603-51040×4iJCG1#200104

main42603-51050×4iJCG10,11200104

42611GVALVE (FOR TUBELESS TIRE)

main90942-05009×4iJCG1#199805-200104

42611JVALVE (FOR TUBELESS TIRE SPARE)

main90942-05009iJCG1#199805-200104

6 parts on this diagram · 2 diagrams in section
