Toyota PICKUP — CAUTION PLATE & NAME PLATE (ENGINE)

Parts diagram
11291PLATE, ENGINE NAME
main11291-35010i198008-198307
22R
sub11291-35030
main11291-38010i197808-198008
20R
11293PLATE, ENGINE CAUTION & ENGINE NAME
main11293-54010i198101-198307
L
11294PLATE, ENGINE CAUTION, NO.2
main11294-34020i197808-198208
11296PLATE, TIMING BELT CAUTION
main11296-54010i198101-198307
17627PLATE, AIR PUMP CAUTION, NO.1
main90917-07065i197808-197908
main90917-07075i197908-198008
17628PLATE, AIR PUMP CAUTION
main17628-38010i197808-198008
17700CPLATE, AIR CLEANER CAUTION (FOR ENGINE MODEL)
main11293-28040i197908-198307
main11293-38040i197808-197908
main90917-07083i198101-198307
17792PLATE, ENGINE VACUUM HOSE INFORMATION
main17792-35061i198008-198108
main17792-35082i198008-198108
CALIFORNIA SPEC
main17792-35092i198008-198108
CALIFORNIA SPEC
main17792-35102i198008-198108
CALIFORNIA SPEC
main17792-35111i198008-198108
main17792-35121i198008-198108
HIGH ALTITUDE SPEC
main17792-35170i198108-198202
main17792-35171i198202-198208
main17792-35180i198108-198208
main17792-35190i198108-198202
HIGH ALTITUDE SPEC
main17792-35191i198202-198208
HIGH ALTITUDE SPEC
main17792-35200i198108-198208
CALIFORNIA SPEC
main17792-35210i198108-198208
CALIFORNIA SPEC
main17792-35290i198208-198307
main17792-35300i198208-198307
CALIFORNIA SPEC
main17792-35310i198208-198307
main17792-35320i198208-198307
HIGH ALTITUDE SPEC
main17792-35330i198208-198307
CALIFORNIA SPEC
main17792-38130i197808-197901
CALIFORNIA SPEC
main17792-38131i197908-198008
CALIFORNIA SPEC
main17792-38140i197808-197901
FEDERAL SPEC
main17792-38141i197908-198008
main17792-38151i197903-197908
main17792-38152i197908-198008
main17792-38161i197901-197908
CALIFORNIA SPEC
main17792-38162i197908-198008
CALIFORNIA SPEC
main17792-38190i197908-198008
23923PLATE, FUEL SEDIMENTER CAUTION
main23923-54010i198101-198307

9 parts on this diagram · 2 diagrams in section
