Toyota MR2 — REAR SPRING & SHOCK ABSORBER
42304CARRIER SUB-ASSY, REAR AXLE, RH
W(*66)
42304DBOLT (FOR REAR AXLE CARRIER RH)
42305CARRIER SUB-ASSY, REAR AXLE, LH
W(*66)
42305ABOLT (FOR REAR AXLE CARRIER LH)
43330HNUT (FOR REAR LOWER BALL JOINT)
43330PBOLT (FOR REAR LOWER BALL JOINT SETTING)
48703EBOLT(FOR REAR SUSPENSION ARM)
*12-1.25PX81-25
*14-1.5PX90-27
48710AARM ASSY, REAR SUSPENSION, NO.1 RH
48720AARM ASSY, REAR SUSPENSION, NO.1 LH
48730AARM ASSY, REAR SUSPENSION, NO.2
48730BEND SUB-ASSY, TIE ROD(FOR REAR SUSPENSION ARM)
48730CTUBE, TIE ROD ADJUSTING(FOR REAR SUSPENSION ARM)
48730FARM ASSY, REAR SUSPENSION, NO.2 RH
48740FARM ASSY, REAR SUSPENSION, NO.2 LH
48750ANUT(FOR REAR SUPPORT TO REAR SHOCK ABSORBER)
48750BCOLLAR(FOR REAR SUPPORT TO REAR SHOCK ABSORBER)
sub90387-15027
48750GNUT(FOR REAR SUSPENSION SUPPORT)
48753COVER, REAR SUSPENSION SUPPORT
48753BCOVER, REAR SUSPENSION SUPOPORT, NO.1 RH
48753CCOVER, REAR SUSPENSION SUPOPORT, NO.1 LH
48780BBOLT(FOR STRUT ROD)
48780CNUT(FOR STRUT ROD)
BODY SIDE
CARRIER SIDE
48787ACOLLER(FOR STRUT BAR CUSHION)
48787BRETAINER, CUSHION(FOR STRUT BAR CUSHION)
48812BAR, STABILIZER, REAR
48832ABRACKET, REAR STABILIZER BAR, NO.1
9011908986
main90119-08986
9017014012
main90170-14012
9017014022
main90170-14022
9017908040
main90179-08040
9017910054
main90179-10054
9017912093
main90179-12093
9017916022
main90179-16022
9017918017
main90179-18017
9020112066
main90201-12066
9020114026
main90201-14026
9020115030
main90201-15030
9020120019
main90201-20019
9462211000
main94622-11000
9538103020
main95381-03020
52 parts on this diagram · 2 diagrams in section
