Toyota LITEACE — CAUTION PLATE & NAME PLATE (ENGINE)

11278PLATE, ENGINE EMISSION IDENTIFICATION

main11278-16020i5K..KM36..RHD..4H198509-198808

SINGAPORE SPEC

sub11278-42010

main11278-54010i1C..CM35..ARL198509-198808

11289PLATE, SPARK PLUG CAUTION

main11289-13040i2YC,3YC..YM30,4#198509-198606

main11289-73020i2YC,3YC..YM30,4#198606-198805

11291PLATE, ENGINE NAME

main11291-13070i5K#..KM3#198509-198808

main11291-72010i2Y#..YM3#198509-198808

main11291-73010i3YC..YM4#198601-198808

11293PLATE, ENGINE CAUTION & ENGINE NAME

main11293-64070i1C..CM35198509-198808

main11293-64080i1C..CM35..LHD198509-198808

CHINA SPEC

11298PLATE, EMISSION CONTROL INFORMATION

main11298-13200i5KC..KM36198509-198805

ADR 36 SPEC

main11298-13220i5KC..KM36198509-198805

main11298-13240i5KC..KM36198805-198808

main11298-72052i2YC..YM35198509-198805

main11298-73041i3YC..YM4#198601-198708

main11298-73110i2YC..YM30198509-198708

main11298-73200i2YC,3YC..YM30,35,40198805-198808

17700CPLATE, AIR CLEANER CAUTION (FOR ENGINE MODEL)

main17791-64020i1C,2C..CM3#198509-198808

main90917-07084i2Y#,3YC..YM3#,4#198509-198808

17700DPLATE, ENGINE CAUTION

main11293-13240i5K..KM3#198509-198808

main11293-13370i5K..KM3#..LHD198509-198808

CHINA SPEC

17792PLATE, ENGINE VACUUM HOSE INFORMATION

main17792-13340i5KC..KM36198509-198805

main17792-13350i5KC..KM36198509-198805

ADR 36 SPEC

main17792-13370i5KC..KM36198805-198808

main17792-73071i2YC..YM35198509-198808

main17792-73190i2YC,3YC..YM30,4#198509-198808

23923PLATE, FUEL SEDIMENTER CAUTION

main23923-64020i1C..CM35198509-198610

main23923-64021i1C,2C..CM3#198610-198808

9 parts on this diagram · 1 diagram in section
