Toyota LITEACE VAN WAGON — CAUTION PLATE & NAME PLATE (ENGINE)

11278PLATE, ENGINE EMISSION IDENTIFICATION

main11278-13010i5K..KR27..RHD199201-199403

SINGAPORE SPEC

main11278-16040i5K..KR27..RHD199403-199408

SINGAPORE SPEC

11289PLATE, SPARK PLUG CAUTION

main11289-13050i5K..KR27..06S199201-199610

HONG KONG SPEC

main11289-73020i3YC,4YEC..YR22,39199201-199603

11291PLATE, ENGINE NAME

main11291-73050i4YEC..YR22199201-199405

11293PLATE, ENGINE CAUTION & ENGINE NAME

main11293-64060i2C..CR27199201-199302

main11293-64080i2C..CR27..LHD199201-199610

CHINA SPEC

11296PLATE, TIMING BELT CAUTION

main11296-13170i5K..KR2#..LHD..4D199201-199610

CHINA SPEC

main11296-72061i3Y..YR21199201-200007

CHINA SPEC

11296ALABEL, ENGINE SERVICE INFORMATION

main11296-64010i2C..CR27199309-199610

11298PLATE, EMISSION CONTROL INFORMATION

main11298-73271i4YEC..YR22199201-199610

main11298-73360i3YC..YR39199201-199610

11299PLATE, IDLE ADJUSTING CAUTION

main11299-13090i5K..KR27..06S199201-199610

HONG KONG SPEC

17700CPLATE, AIR CLEANER CAUTION (FOR ENGINE MODEL)

main11296-55020i2C..CR27199301-199505

main11296-64020i2C..CR27199505-199610

main17791-64020i2C..CR27199201-199301

main90917-07084i3Y#,4YEC..YR2#,39199201-199603

17700DPLATE, ENGINE CAUTION

main11293-13330i5K..KR27..5D..03S199408-199610

SINGAPORE SPEC

17791LABEL, MAINTENANCE INFORMATION

main17791-55010i2C..CR27199201-199610

17792PLATE, ENGINE VACUUM HOSE INFORMATION

main11296-13160i5K..KR2#199201-199610

main17792-13450i5K..KR27..06S199201-199610

HONG KONG SPEC

main17792-13460i5K..KR27..06S;5K..KR27..5D..03S199311-199408

SINGAPORE SPEC

main17792-73381i4YEC..YR22199201-199405

main17792-73420i3YC..YR39199201-199610

23923PLATE, FUEL SEDIMENTER CAUTION

main23923-64021i2C..CR27199201-199610

1356410010LABEL, TIMING BELT REPLACEMENT INFORMATION

main13564-10010

14 parts on this diagram · 1 diagram in section
