Toyota LEXUS RX SERIES — SWITCH & RELAY & COMPUTER

0001 1ENGINE & TRANSMISSION 0002 1ENGINE & TRANSMISSION 0003 1ENGINE ROOM(1/2) 0004 1ENGINE ROOM(1/2) 0005 1ENGINE ROOM(2/2) 0006 1ENGINE ROOM(2/2) 0007 1COWL 0008 1COWL 0009 1COWL 0010 1COWL 0011 1INSTRUMENT PANEL(1/2) 0012 1INSTRUMENT PANEL(1/2) 0013 1INSTRUMENT PANEL(2/2) 0014 1INSTRUMENT PANEL(2/2) 0015 1INSTRUMENT PANEL(2/2) 0016 1INSTRUMENT PANEL(2/2) 0017 1STEERING 0018 1SEAT 0019 1DOOR, ROOF & FLOOR 0020 1LUGGAGE & BACK DOOR 0021 1LUGGAGE & BACK DOOR

83520GAGE ASSY,OIL PRESSURE SENDER

main83520-60060iAGL2#201509-201908

84540SWITCH ASSY, NEUTRAL START

main84540-33010iAGL2#201509-201908

main84540-48030iGGL25201509-201908

89429FSENSOR, TEMPERATURE

main89429-12010iAGL2#201509-201908

89439BRACKET, SENSOR

main89439-48020iAGL2#..LHD201803-201908

GEORGIA SPEC

main89439-48020iAGL2#..LHD201803-201908

UKRAINE SPEC

main89439-48020iAGL2#..LHD201803-201908

ARMENIA SPEC

main89439-48020iAGL2#..LHD201803-201908

AZERBAIJAN SPEC

main89439-48020iAGL2#..LHD201803-201908

ADRIA(SLOVENIA) SPEC

main89439-48020iAGL2#..LHD201803-201908

BELARUS SPEC

main89439-48020iAGL2#..LHD201803-201908

KAZAKHSTAN SPEC

main89439-48020iAGL2#..LHD201803-201908

SERBIA SPEC

main89439-48020iAGL2#..LHD201803-201908

RUSSIA,BELARUS,KAZAKHSTAN SPEC

main89439-48020iAGL2#201908

89465SENSOR, OXYGEN

main89465-48400iGGL25201509-201908

main89465-48410iGYL25201510-201908

main89465-48420iAGL2#201509-201803

main89467-48330iAGL2#201803-201908

89467BSENSOR, AIR FUEL RATIO

main89467-48310iGGL25,GYL25201509-201908

main89467-78010iAGL2#201509-201908

89481BSENSOR, DIFFERENTIAL PRESSURE

main89481-71010iAGL2#..LHD201803-201908

ARMENIA SPEC

main89481-71010iAGL2#..LHD201803-201908

AZERBAIJAN SPEC

main89481-71010iAGL2#..LHD201803-201908

ADRIA(SLOVENIA) SPEC

main89481-71010iAGL2#..LHD201803-201908

BELARUS SPEC

main89481-71010iAGL2#..LHD201803-201908

KAZAKHSTAN SPEC

main89481-71010iAGL2#..LHD201803-201908

SERBIA SPEC

main89481-71010iAGL2#..LHD201803-201908

RUSSIA,BELARUS,KAZAKHSTAN SPEC

main89481-71010iAGL2#..LHD201803-201908

UKRAINE SPEC

main89481-71010iAGL2#..LHD201803-201908

GEORGIA SPEC

main89481-71010iAGL2#201908

89491SENSOR, ENGINE OIL LEVEL

main89491-48020iGGL25,GYL25201509-201808

sub89491-48021

main89491-48021iGGL25,GYL25201809-202004

sub89491-48040

main89491-48040iGGL25,GYL25202005-202204

sub89491-48041

main89491-48041iGGL25,GYL25202205

main89491-78020iAGL2#201509-201808

sub89491-78021

main89491-78021iAGL2#201809-201908

89615SENSOR, KNOCK CONTROL

main89615-20090iAGL2#201509-201908

8271548A20BRACKET,WIRING HARNESS CLAMP

main82715-48A20

8271578020BRACKET,WIRING HARNESS CLAMP

main82715-78020

9043012026

main90430-12026

9046815007

main90468-15007

9155180620

main91551-80620

9155180835

main91551-80835

9165140620

main91651-40620

9167180612

main91671-80612

9167180614

main91671-80614

9167180616

main91671-80616

19 parts on this diagram · 21 diagrams in section
