Toyota LEXUS LS400 — SWITCH & RELAY & COMPUTER

0001 1 0002 1 0003 1 0004 1 0005 1 0006 1 0007 1 0008 1

83420GAGE ASSY, WATER TEMPERATURE SENDER

main83420-16020iUCF10198905-199208

main83420-16050iUCF10199208-199410

sub83420-20040

83530SWITCH ASSY, OIL PRESSURE (FOR ENGINE)

main83530-14060iUCF10199208-199410

sub83530-30090

main83530-30080iUCF10198905-199208

sub83530-60040

84540SWITCH ASSY, NEUTRAL START

main84540-30270iUCF10199208-199410

TOKAIRIKA

main84540-30280iUCF10199208-199410

MATSUSHITA

main84540-50010iUCF10198905-199208

89437COVER, SENSOR

main89437-50010iUCF10198905-199410

RH

main89437-50020iUCF10198905-199410

LH

89465SENSOR, OXYGEN

main89465-50010×2iUCF10198905-199410

FRONT

main89465-50020×2iUCF10198905-199208

REAR

main89465-50050×2iUCF10199208-199410

REAR

89491SENSOR, ENGINE OIL LEVEL

main89491-30030iUCF10199109-199208

main89491-50010iUCF10198905-199109

main89491-50020iUCF10199208-199410

89615SENSOR, KNOCK CONTROL

main89615-20010×2iUCF10198905-199005

main89615-50010×2iUCF10199005-199410

9015960386

main90159-60386

9043027001

main90430-27001

9165140830

main91651-40830

10 parts on this diagram · 8 diagrams in section
