Toyota LEXUS LS SERIES — REAR STEERING GEAR (4WS)

45520ROD ASSY, REAR STEERING TIE, RH

main45520-19005i201710-201909

"F SPORT"*(F)&SUSPENSION-AIR SUSPENSION & *AVS

45530ROD ASSY, REAR STEERING TIE, LH

main45530-19005i201710-201909

"F SPORT"*(F)&SUSPENSION-AIR SUSPENSION & *AVS

45900LINK ASSY, REAR STEERING

main45900-50010i201710-201909

"F SPORT"*(F)&SUSPENSION-AIR SUSPENSION & *AVS

main45900-50020i202310-202410

"F SPORT"*(F)

main45900-50021i202411-202509

"F SPORT"*(F)

9017712001

main90177-12001

9017816001

main90178-16001

9017906178

main90179-06178

91552K1225

main91552-K1225

7 parts on this diagram · 1 diagram in section

REAR STEERING GEAR (4WS) for Toyota LEXUS LS SERIES

This section contains 7 genuine Toyota parts for the REAR STEERING GEAR (4WS) system of the Toyota LEXUS LS SERIES. Key components include: ROD ASSY, REAR STEERING TIE, RH, ROD ASSY, REAR STEERING TIE, LH, LINK ASSY, REAR STEERING.
