Toyota LEXUS LFA — REAR COMBINATION LAMP

Parts diagram

5202REAR BUMPER & BUMPER STAY

→ Go to FIG 52-02

6101SIDE MEMBER

→ Go to FIG 61-01

81550LAMP ASSY, REAR COMBINATION, RH

main81550-77020i201012

81550BBULB(FOR REAR COMBINATION LAMP)

main90981-13043×2i201012-201212

12V 21W

81550ECLIP(FOR REAR COMBINATION LAMP)

main81559-77010×2i201012

81560LAMP ASSY, REAR COMBINATION, LH

main81560-77020i201012

9010506298

main90105-06298

9010906196

main90109-06196

9018306030

main90183-06030

9 parts on this diagram · 1 diagram in section

REAR COMBINATION LAMP for Toyota LEXUS LFA

This section contains 9 genuine Toyota parts for the REAR COMBINATION LAMP system of the Toyota LEXUS LFA. Key components include: REAR BUMPER & BUMPER STAY, SIDE MEMBER, LAMP ASSY, REAR COMBINATION, RH, BULB(FOR REAR COMBINATION LAMP), CLIP(FOR REAR COMBINATION LAMP).
