Toyota LEXUS LC500/500H — REAR STEERING GEAR (4WS)
45520ROD ASSY, REAR STEERING TIE, RH
"S+ PACKAGE"
45530ROD ASSY, REAR STEERING TIE, LH
"S+ PACKAGE"
45900LINK ASSY, REAR STEERING
"S+ PACKAGE"
9017712001
main90177-12001
9017906178
main90179-06178
91552K1225
main91552-K1225
6 parts on this diagram · 1 diagram in section
REAR STEERING GEAR (4WS) for Toyota LEXUS LC500/500H
This section contains 6 genuine Toyota parts for the REAR STEERING GEAR (4WS) system of the Toyota LEXUS LC500/500H. Key components include: ROD ASSY, REAR STEERING TIE, RH, ROD ASSY, REAR STEERING TIE, LH, LINK ASSY, REAR STEERING.
