Toyota HILUX (SCB/XTR) — SWITCH & RELAY & COMPUTER
1708VACUUM PIPING
83520GAGE ASSY,OIL PRESSURE SENDER
main83520-60060iGUN122..LHD..GEN;GUN135..ARL,BZAG,KEN,TH;GUN11#,12#,136..ARL,BZAG,GCC,IDN,KEN,LA,MA,PH,TH; GUN125..LHD..L..GEN; GUN125..RHD..GEN; GUN125..S..GEN; GUN135..L..SA;GUN125..RHD..SCB..6F..(GEN,SA)..CBU202408
CAMBODIA SPEC&EXHAUST EMISSION CONTROL-EURO 4 WITH(ON BOARD DIAGNOSIS); COSTA RICA SPEC&EXHAUST EMISSION CONTROL-EURO 4 WITH(ON BOARD DIAGNOSIS); EXHAUST EMISSION CONTROL-EURO 4 WITH(ON BOARD DIAGNOSIS); EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS)
83530SWITCH ASSY, OIL PRESSURE (FOR ENGINE)
main83530-28010iGUN112..L..GCC; GUN122..LHD..GEN; GUN125..LA..CBU;GUN122..GCC..CBU;GUN112,122..L..GCC; GUN125..LHD..L..GEN; GUN125..RHD..GEN; GUN125..S..GEN; GUN135..L..SA;GUN125..RHD..SCB..6F..(GEN,SA)..CBU; GUN135..LA,SA;GUN122..RHD..5F;GUN122..LHD..SA;GUN125,126,136..GEN,SA202408
ASEAN GENERAL SPEC,DENSO,*369; CAMBODIA SPEC,DENSO,*369; CENTRAL AND SOUTH AMERICA SPEC,DENSO,*369; COSTA RICA SPEC,DENSO,*369; DENSO,*369; EXHAUST EMISSION CONTROL-EURO 2 WITHOUT(ON BOARD DIAGNOSIS),DENSO,*369; EXHAUST EMISSION CONTROL-EURO 4 WITH(ON BOARD DIAGNOSIS),DENSO,*369; EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS),DENSO,*369; EXHAUST EMISSION CONTROL-WITHOUT,DENSO,*369
DENSO,*369
main83530-60010iGUN112..L..GCC; GUN122..LHD..GEN; GUN125..LA..CBU;GUN122..GCC..CBU;GUN112,122..L..GCC; GUN135..LA,SA;GUN122..RHD..5F;GUN122..LHD..SA;GUN125,126,136..GEN,SA202408
ASEAN GENERAL SPEC,YAZAKI,*369; CENTRAL AND SOUTH AMERICA SPEC,YAZAKI,*369; EXHAUST EMISSION CONTROL-EURO 2 WITHOUT(ON BOARD DIAGNOSIS),YAZAKI,*369; EXHAUST EMISSION CONTROL-WITHOUT,YAZAKI,*369; YAZAKI,*369
YAZAKI,*369
DENSO,*369
89425SENSOR, EXHAUST GAS TEMPERATURE
main89425-71070iGUN112..L;GUN125..AGTP..LA;GUN125..ARL,BZAG,TH;GUN111,120,121,122,126,13#..(6F,6FC)..(ARL,BZAG,GCC,TH); GUN112..S;GUN122,125..GCC; GUN122,125..L..GCC; GUN122..GCC..CBU; GUN122..L..GCC; GUN125..RHD..GEN; GUN126..LA;GUN125..THP..LA202408
EXHAUST EMISSION CONTROL-EURO 6B WITH(ON BOARD DIAGNOSIS); GCC SPEC EURO4 2022MY&EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS); IRAQ SPEC&EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS); JORDAN SPEC&EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS); OCEANIA(EURO 5 REGULATION)&EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS); SAUDI ARABIA SPEC&EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS)
89425ASENSOR, EXHAUST GAS TEMPERATURE, NO.2
main89425-71080iGUN112..L;GUN125..AGTP..LA;GUN125..ARL,BZAG,TH;GUN111,120,121,122,126,13#..(6F,6FC)..(ARL,BZAG,GCC,TH); GUN112..S;GUN122,125..GCC; GUN122,125..L..GCC; GUN122..GCC..CBU; GUN122..L..GCC; GUN125..RHD..GEN; GUN126..LA;GUN125..THP..LA202408
EXHAUST EMISSION CONTROL-EURO 6B WITH(ON BOARD DIAGNOSIS); GCC SPEC EURO4 2022MY&EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS); IRAQ SPEC&EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS); JORDAN SPEC&EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS); OCEANIA(EURO 5 REGULATION)&EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS); SAUDI ARABIA SPEC&EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS)
89425BSENSOR, EXHAUST GAS TEMPERATURE, NO.3
main89425-71090iGUN112..L;GUN125..AGTP..LA;GUN125..ARL,BZAG,TH;GUN111,120,121,122,126,13#..(6F,6FC)..(ARL,BZAG,GCC,TH); GUN112..S;GUN122,125..GCC; GUN122,125..L..GCC; GUN122..GCC..CBU; GUN122..L..GCC; GUN125..RHD..GEN; GUN126..LA;GUN125..THP..LA202408
EXHAUST EMISSION CONTROL-EURO 6B WITH(ON BOARD DIAGNOSIS); GCC SPEC EURO4 2022MY&EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS); IRAQ SPEC&EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS); JORDAN SPEC&EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS); OCEANIA(EURO 5 REGULATION)&EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS); SAUDI ARABIA SPEC&EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS)
89425CSENSOR, EXHAUST GAS TEMPERATURE, NO.4
CENTRAL AND SOUTH AMERICA SPEC&EXHAUST EMISSION CONTROL-WITHOUT; COSTA RICA SPEC&EXHAUST EMISSION CONTROL-EURO 4 WITH(ON BOARD DIAGNOSIS); EXHAUST EMISSION CONTROL-TIER 2.5; PERU SPEC&EXHAUST EMISSION CONTROL-EURO 4 WITH(ON BOARD DIAGNOSIS); URUGUAY SPEC&EXHAUST EMISSION CONTROL-EURO 4 WITH(ON BOARD DIAGNOSIS); URUGUAY SPEC&EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS)
EXHAUST EMISSION CONTROL-TIER 2.5
89439DBRACKET, SENSOR, NO.1
CENTRAL AND SOUTH AMERICA SPEC&EXHAUST EMISSION CONTROL-WITHOUT; COSTA RICA SPEC&EXHAUST EMISSION CONTROL-EURO 4 WITH(ON BOARD DIAGNOSIS); PERU SPEC&EXHAUST EMISSION CONTROL-EURO 4 WITH(ON BOARD DIAGNOSIS); URUGUAY SPEC&EXHAUST EMISSION CONTROL-EURO 4 WITH(ON BOARD DIAGNOSIS)
89463ASENSOR, NITROGEN OXIDES
CENTRAL AND SOUTH AMERICA SPEC&EXHAUST EMISSION CONTROL-WITHOUT,REAR; COSTA RICA SPEC&EXHAUST EMISSION CONTROL-EURO 4 WITH(ON BOARD DIAGNOSIS),REAR; EXHAUST EMISSION CONTROL-TIER 2.5,REAR; PERU SPEC&EXHAUST EMISSION CONTROL-EURO 4 WITH(ON BOARD DIAGNOSIS),REAR; REAR; URUGUAY SPEC&EXHAUST EMISSION CONTROL-EURO 4 WITH(ON BOARD DIAGNOSIS),REAR; URUGUAY SPEC&EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS),REAR
CENTRAL AND SOUTH AMERICA SPEC&EXHAUST EMISSION CONTROL-WITHOUT,FRONT; COSTA RICA SPEC&EXHAUST EMISSION CONTROL-EURO 4 WITH(ON BOARD DIAGNOSIS),FRONT; FRONT; PERU SPEC&EXHAUST EMISSION CONTROL-EURO 4 WITH(ON BOARD DIAGNOSIS),FRONT; URUGUAY SPEC&EXHAUST EMISSION CONTROL-EURO 4 WITH(ON BOARD DIAGNOSIS),FRONT
89467BSENSOR, AIR FUEL RATIO
main89467-71120iGUN112..L;GUN125,135..ARL,BZAG,TH;GUN111,120,121,122,126,136..THP..(6F,6FC); GUN112..S;GUN122,125..GCC; GUN122,125..L..GCC; GUN122..GCC..CBU; GUN122..L..GCC; GUN125..RHD..GEN; GUN126..LA;GUN125..LA..CBU202408
EXHAUST EMISSION CONTROL-EURO 6B WITH(ON BOARD DIAGNOSIS); GCC SPEC EURO4 2022MY&EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS); IRAQ SPEC&EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS); JORDAN SPEC&EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS); OCEANIA(EURO 5 REGULATION)&EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS); SAUDI ARABIA SPEC&EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS)
8946ABRACKET, EXHAUST SENSOR CLAMP
CENTRAL AND SOUTH AMERICA SPEC&EXHAUST EMISSION CONTROL-WITHOUT; COSTA RICA SPEC&EXHAUST EMISSION CONTROL-EURO 4 WITH(ON BOARD DIAGNOSIS); PERU SPEC&EXHAUST EMISSION CONTROL-EURO 4 WITH(ON BOARD DIAGNOSIS); URUGUAY SPEC&EXHAUST EMISSION CONTROL-EURO 4 WITH(ON BOARD DIAGNOSIS)
89481BSENSOR, DIFFERENTIAL PRESSURE
main89481-71010iGUN112..L;GUN125..AGTP..LA;GUN125,135..ARL,BZAG,TH;GUN111,120,121,122,126,136..THP..(6F,6FC); GUN112..S;GUN125..GCC;GUN122..S..IV3; GUN122..L..GCC;GUN122..GCC..CBU;GUN125..RHD..GEN; GUN125..GCC; GUN126..LA;GUN125..THP..LA202408
EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS); EXHAUST EMISSION CONTROL-EURO 6B WITH(ON BOARD DIAGNOSIS); GCC SPEC EURO4 2022MY&EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS); SAUDI ARABIA SPEC&EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS)
89491SENSOR, ENGINE OIL LEVEL
894A0SENSOR ASSY, PARTICULATE MATTER
EXHAUST EMISSION CONTROL-TIER 2.5
8271571200BRACKET,WIRING HARNESS CLAMP
main82715-71200
8946A71020BRACKET, EXHAUST SENSOR CLAMP
main8946A-71020
8946A71030BRACKET, EXHAUST SENSOR CLAMP
main8946A-71030
8946AKK010BRACKET, EXHAUST SENSOR CLAMP
main8946A-KK010
90105T0066
main90105-T0066
90119T0134
main90119-T0134
90119T0260
main90119-T0260
90119T0287
main90119-T0287
90178T0007
main90178-T0007
90178T0018
main90178-T0018
9155180612
main91551-80612
9167180616
main91671-80616
9167380616
main91673-80616
9167380820
main91673-80820
9415180600
main94151-80600
9622110706
main96221-10706
30 parts on this diagram · 19 diagrams in section
SWITCH & RELAY & COMPUTER for Toyota HILUX (SCB/XTR)
This section contains 189 genuine Toyota parts for the SWITCH & RELAY & COMPUTER system of the Toyota HILUX (SCB/XTR). Key components include: VACUUM PIPING, RELAY ASSY, STARTER, RELAY ASSY, STARTER, NO.2, RELAY, IGNITION, NO.1, RELAY, IGNITION, NO.2.
