Toyota HILUX (DOUBLE CAB) — SWITCH & RELAY & COMPUTER
83530SWITCH ASSY, OIL PRESSURE (FOR ENGINE)
main83530-28010iGUN122..IV3; GUN122..S..GEN; GUN125..6FC..S..GEN;GUN125..LHD..(H,L)..GEN;GUN126..RHD..6FC..H..GEN; GUN125..H..GCC;GUN122..S..GCC..CBU; GUN125..H..GCC;GUN125..6F..L..GCC;GUN125..AGTP..L..LA;GUN125..RHD..L..GEN;GUN126..H..DCRL..LA;GUN125..LHD..S..(GEN,LA);GUN122,135..(L,S)..(GCC,LA)..CBU; GUN125..RHD..H..GEN; GUN125..THP..L..LA; GUN126..RHD..6FC..GEN;GUN125..RHD..6F..S..GEN;GUN125..RHD..6FC..S..(GEN,SA);GUN125,126..RHD..6F..(H,L)..SA;GUN126..LHD..(MMRP,THP)..6FC..H..(GEN,MMR); GUN136..LA,SA;GUN125..GHA,SA;GUN126..6F..H..SA;GUN126..6FC..S..LA;GUN122,135..GEN,SA;GUN125..RHD..(H,S)..GEN;GUN126..6F..S..(GEN,SA);GUN126..LHD..6F..H..GEN;GUN125..LHD..THP..(H,L)..(GEN,LA);GUN126..(GHAP,MMRP,SAP,THP)..6FC..(GEN,GHA,MMR,SA)202408
CAMBODIA SPEC,DENSO,*369; COSTA RICA SPEC,DENSO,*369; DENSO,*369; EXHAUST EMISSION CONTROL-EURO 2 WITHOUT(ON BOARD DIAGNOSIS),DENSO,*369; EXHAUST EMISSION CONTROL-EURO 4 WITH(ON BOARD DIAGNOSIS),DENSO,*369; EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS),DENSO,*369; EXHAUST EMISSION CONTROL-WITHOUT,DENSO,*369; OCEANIA(EURO 5 REGULATION),DENSO,*369; SYRIA SPEC,DENSO,*369
DENSO,*369
main83530-60010iGUN122..IV3; GUN125..H..GCC;GUN122..S..GCC..CBU; GUN125..H..GCC;GUN125..6F..L..GCC;GUN125..AGTP..L..LA;GUN125..RHD..L..GEN;GUN126..H..DCRL..LA;GUN125..LHD..S..(GEN,LA);GUN122,135..(L,S)..(GCC,LA)..CBU; GUN136..LA,SA;GUN125..GHA,SA;GUN126..6F..H..SA;GUN126..6FC..S..LA;GUN122,135..GEN,SA;GUN125..RHD..(H,S)..GEN;GUN126..6F..S..(GEN,SA);GUN126..LHD..6F..H..GEN;GUN125..LHD..THP..(H,L)..(GEN,LA);GUN126..(GHAP,MMRP,SAP,THP)..6FC..(GEN,GHA,MMR,SA)202408
EXHAUST EMISSION CONTROL-EURO 2 WITHOUT(ON BOARD DIAGNOSIS),YAZAKI,*369; EXHAUST EMISSION CONTROL-WITHOUT,YAZAKI,*369; SYRIA SPEC,YAZAKI,*369; YAZAKI,*369
YAZAKI,*369
DENSO,*369
89465SENSOR, OXYGEN
89465ASENSOR, OXYGEN NO.2
89467BSENSOR, AIR FUEL RATIO
main89467-71120iGUN122,125..GCC; GUN122..L..GCC;GUN125..H..GCC; GUN125,135..S..LA;GUN126..6F..S..LA;GUN135..THP..L..LA;GUN126..AGTP..(H,L)..LA;GUN126..THP..H..DCRL..LA; GUN125..6FC..L..GEN; GUN125..6FC..S..GEN;GUN126..RHD..6FC..H..GEN;GUN125..RHD..6F..(H,L)..GEN; GUN125..H..GCC;GUN122,125..MTM..L..GCC; GUN125..H..GCC;GUN125..6F..L..GCC;GUN122..S..GCC..CBU; GUN125..LHD..(H,L)..GEN; GUN125..LHD..S..GEN; GUN126..S..IV3;GUN126..H..BZAG;GUN126..MHV..LA;GUN136..6F..BZAG;GUN126..H..MHV..IV3;GUN135..AGTP..L..LA;GUN126..6F..S..BZAG;GUN135..ARL,BZAG,TH,VN;GUN136..6FC..(ARL,BZAG);GUN125..6F..(ARL,BZAG,TH,VN);GUN125..6FC..L..(ARL,BZAG,GEN);GUN120,121,122,126..(6F,6FC)..(ARL,GCC,TH,VN)..CBU; GUN126..THP..6FC..H..DCRL..LA; GUN126..THP..L;GUN125..AGTP..L..LA202408
ASIA COLD COUNTRY SPEC&EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS); AZERBAIJAN SPEC&EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS); EXHAUST EMISSION CONTROL-EURO 4 WITH(ON BOARD DIAGNOSIS); EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS); EXHAUST EMISSION CONTROL-EURO 6B WITH(ON BOARD DIAGNOSIS); EXHAUST EMISSION CONTROL-EURO 6C,EURO 6D WITH(ON BOARD DIAGNOSIS); EXHAUST EMISSION CONTROL-WITHOUT; GCC SPEC EURO4 2022MY&EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS); IRAQ SPEC&EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS); JORDAN SPEC&EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS); MEXICO SPEC&EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS); NEPAL,SRI LANKA SPEC(EURO 4 REGULATION)&EXHAUST EMISSION CONTROL-EURO 4 WITH(ON BOARD DIAGNOSIS); OCEANIA(EURO 5 REGULATION)&EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS); SAUDI ARABIA SPEC&EXHAUST EMISSION CONTROL-EURO 5 WITH(ON BOARD DIAGNOSIS)
89615SENSOR, KNOCK CONTROL
8271571180BRACKET,WIRING HARNESS CLAMP
main82715-71180
8271571210BRACKET,WIRING HARNESS CLAMP
main82715-71210
90119T0134
main90119-T0134
9155180830
main91551-80830
9 parts on this diagram · 23 diagrams in section
SWITCH & RELAY & COMPUTER for Toyota HILUX (DOUBLE CAB)
This section contains 235 genuine Toyota parts for the SWITCH & RELAY & COMPUTER system of the Toyota HILUX (DOUBLE CAB). Key components include: VACUUM PIPING, RELAY ASSY, STARTER, RELAY ASSY, STARTER, NO.2, RELAY, IGNITION, NO.1, RELAY, IGNITION, NO.2.
