Toyota FJ CRUISER — SWITCH & RELAY & COMPUTER

0001 1����� & ��������� 0002 1�������� 0003 1��� 0004 1������������ 1/2 0005 1������������ 2/2 0006 1������� 0007 1���,���,��� & �������

83530SWITCH ASSY, OIL PRESSURE (FOR ENGINE)

main83530-60020iGSJ15201011-201801

84222SWITCH, TRANSFER INDICATOR, NO.1

main84222-35080iGSJ15201011-201801

84222BSWITCH, TRANSFER INDICATOR, NO.2

main84222-35090iGSJ15201011-201801

84222CSWITCH, TRANSFER INDICATOR, NO.3

main84222-35110iGSJ15201011-201801

84540SWITCH ASSY, NEUTRAL START

main84540-04010iGSJ15201011-201801

main84540-71010iGSJ15201011-201801

main84540-71010iGSJ15201508-201604

89465SENSOR, OXYGEN

main89465-60320iGSJ15201011-201801

89465ASENSOR, OXYGEN NO.2

main89465-60430iGSJ15201011-201801

89467BSENSOR, AIR FUEL RATIO

main89467-60060iGSJ15201011-201801

89467CSENSOR, AIR FUEL RATIO, NO.2

main89467-60060iGSJ15201011-201801

89615SENSOR, KNOCK CONTROL

main89615-20090iGSJ15201011-201801

8271535C10BRACKET,WIRING HARNESS CLAMP

main82715-35C10

8271560P10BRACKET,WIRING HARNESS CLAMP

main82715-60P10

9011908C62

main90119-08C62

9155180830

main91551-80830

9167180612

main91671-80612

15 parts on this diagram · 7 diagrams in section
