Toyota DYNA100 — CAUTION PLATE & NAME PLATE (ENGINE)

11278PLATE, ENGINE EMISSION IDENTIFICATION

main11278-54010i2L..LH80..ARL198508-198708

main11278-72011i2Y..YH81..ARL198508-198708

11291PLATE, ENGINE NAME

main11291-71010i1Y..YH80198508-198708

main11291-72010i2Y..YH81198508-198708

11293PLATE, ENGINE CAUTION & ENGINE NAME

main11293-54030i2L..LH80198508-198708

main11293-72040i1Y..YH80..LHD198508-198708

CHINA SPEC

17700CPLATE, AIR CLEANER CAUTION (FOR ENGINE MODEL)

main17791-64020i2L,1Y,2Y..LH80,YH8#198508-198708

main17791-73010i1Y..YH80..LHD198508-198708

CHINA SPEC

17792PLATE, ENGINE VACUUM HOSE INFORMATION

main17792-71050i2Y..YH81..EUR198508-198708

23923PLATE, FUEL SEDIMENTER CAUTION

main23923-54040i2L..LH80..ARL,GEN198508-198708

6 parts on this diagram · 1 diagram in section
