Toyota DYNA — INTERIOR LAMP

81240LAMP ASSY, ROOM, NO.1

main81240-95401×2i197708-198008

24V

main81240-95A04×2i197708-198408

12V

81240BBULB, ROOM LAMP, NO.1

main90981-11004×2i197708-198408

12V 10W,12V 10W

main90981-16019×2i197708-198008

24V 10W,24V 10W

8701MIRROR

→ Go to FIG 87-01

9015040004

main90150-40004

4 parts on this diagram · 1 diagram in section

INTERIOR LAMP for Toyota DYNA

This section contains 4 genuine Toyota parts for the INTERIOR LAMP system of the Toyota DYNA. Key components include: LAMP ASSY, ROOM, NO.1, BULB, ROOM LAMP, NO.1, MIRROR.
