Toyota DYNA — ELECTRONIC DIESEL INJECTION CONTROL SYSTEM

0001 1 0002 1

28571MOTOR, FUEL CONTROL

main28571-56020iH..HU30197708-198008

12V

main28571-56030iB..BU2#,30..ARL,GEN197708-198008

12V

main28571-56050iB..BU20,30..EUR197708-198008

24V

main28571-56070i2J..JU20197708-197904

24V

main28571-56080iH..HU30..RHD..GEN197708-197907

12V,W/EXHAUST BRAKE

main28571-56090iB..BU20,30..RHD..WT197708-197907

12V,W/EXHAUST BRAKE

main28571-56120iB,2B,3B..BU2#,3#,40..ARL,GEN,GHI198204-198411

12V

main28571-56130i3B..BU40..LHD198302-198408

24V

main28571-56140i2H..HU40,50198204-198408

12V

main28571-56160iH..HU30198008-198104

12V

28571AROD, FUEL CONTROL MOTOR

main84580-36011iH..HU30197708-198104

main84580-36021iB,2B,3B..BU2#,3#,40198204-198411

main84580-36031i2J..JU20197708-197904

main84580-36040i2H..HU40,50198204-198408

28578COVER, FUEL CONTROL MOTOR

main28578-56010iB,2B,3B..BU2#,3#..DMP,TR,V198104-198204

28579BRACKET, FUEL CONTROL MOTOR

main28579-56020iH..HU30197708-198104

main28579-56030iB,2B,3B..BU2#,3#,40198204-198411

main28579-56040i2J..JU20197708-197904

28590RELAY ASSY, FUEL CONTROL

main28590-56021iB,H..BU2#,30,HU30..ARL,GEN197708-198008

12V

main28590-56031iB,2J..BU20,30,JU20..EUR197708-198008

24V

main28590-56040iB,H..BU20,30,HU30..RHD..WT..GEN197708-197907

12V,W/EXHAUST BRAKE

main28590-56090iB,2B,3B,2H..BU2#,3#,40,HU40,50..ARL,GEN,GHI198204-198411

12V

main28590-56100iB..BU20..ST..EUR;B..BU20,25,30..LHD..5H..WT198104-198408

24V

7819710010CLIP, ACCELERATOR JOINT BALL

main78197-10010

9046108187

main90461-08187

9046108265

main90461-08265

9161160665

main91611-60665

9161160825

main91611-60825

9165140616

main91651-40616

9461111200

main94611-11200

12 parts on this diagram · 2 diagrams in section
