Toyota DYNA — ABS & VSC

0001 1 0003 1FRONT SPEED SENSOR 0005 1REAR SPEED SENSOR 0006 1

88263ARELAY, SKID CONTROL

main88263-36040iBU300,340200212-200312

88263ERELAY, SKID CONTROL NO.2

main88263-36050iXZU305,345200212-200610

89421FSENSOR, VACUUM (FOR SKID CONTROL)

main89421-37010×2iXZU305,345200212-200610

sub89421-37030

89540COMPUTER ASSY, SKID CONTROL

main89540-37031iBU300200212-200312

main89540-37061iWU340..SA200212-200802

main89540-37200iXZU305200312-200610

PART NUMBER LABEL=89540-37200

main89540-37210iWU340..SA200802-200812

main89540-37220iXZU305200312-200610

PART NUMBER LABEL=89540-37220

main89540-37230iXZU345200312-200610

PART NUMBER LABEL=89540-37230

89549BRACKET, SKID CONTROL COMPUTER

main89549-37040iXZU305,345200312-200610

main89549-37050iXZU307,327,337,347200610-200901

9162140616

main91621-40616

9356855016

main93568-55016

7 parts on this diagram · 4 diagrams in section
