Toyota DYNA — ELECTRONIC DIESEL INJECTION CONTROL SYSTEM

28571MOTOR, FUEL CONTROL

main28571-56130iB..BU75198708-198808

28578COVER, FUEL CONTROL MOTOR

main28578-56010iB..BU75198708-198808

28579BRACKET, FUEL CONTROL MOTOR

main28579-56030iB..BU75198708-198808

28590RELAY ASSY, FUEL CONTROL

main28590-57020iB..BU75198708-198808

84580BROD ASSY, CONNECTING

main84580-36021iBU75198708-198808

7819710010CLIP, ACCELERATOR JOINT BALL

main78197-10010

9046108265

main90461-08265

9161160665

main91611-60665

9165160825

main91651-60825

9418040500

main94180-40500

10 parts on this diagram · 1 diagram in section
