Toyota DYNA 200 — ROOF PANEL & BACK PANEL

0001 1 0002 1 0003 1

53701APRON SUB-ASSY, FRONT FENDER, RH

main53701-95407iBU60..T3;BU66..T3..TB;BU61,65,67,83,84,87199011-199505

main53701-95407iBU60..ST..IV3;BU61,66..LHD..IV3199004-199011

TAIWAN SPEC

main53701-95408iBU60,61,65,83,84,87..RHD..(GEN,GHD)198808-199011

main53703-92600iBU70198808-199505

main53703-92607iBU88..TW1198808-199505

main53717-95410iBU88..LHD..IV3198808-199011

TAIWAN SPEC

main53717-95410iBU91,96..TD199004-199703

main53717-95411iBU60..TW1199011-199505

main53717-95413iBU60..TW1198808-199011

main53717-95414iBU88,9#..T3198808-199011

53702APRON SUB-ASSY, FRONT FENDER, LH

main53702-95412iBU60..ST..IV3;BU61,66..LHD..IV3199004-199011

TAIWAN SPEC

main53702-95412iBU60..T3;BU66..T3..TB;BU61,65,67,83,84,87199011-199505

main53702-95413iBU60..T3;BU61,65,66,67,83,84,87198808-199011

main53704-92600iBU88..TW1198808-199505

main53704-92601iBU70198808-199505

main53718-95411iBU88..LHD..IV3198808-199011

TAIWAN SPEC

main53718-95411iBU91,96..TD199004-199703

main53718-95412iBU60..TW1199011-199505

main53718-95414iBU60..TW1;BU88,9#..T3..DSL198808-199011

main53718-95415iBU91..ARL199008-199011

W(*AIC)

main53718-95415iBU91..ARL199008-199011

W(PTO OR FRONT SEAT BELT 3P ELR OR *AIC)

main53718-95415iBU91..ARL199008-199011

AUSTRALIA SPEC OR W(PTO)

main53718-95415iBU91..ARL199008-199011

W(PTO OR *AIC)

main53718-95415iBU88,94..IV1199008-199011

W(PTO)

main53718-95415iBU88,9#..T3198808-199008

58183BREINFORCEMENT, REAR MOUNTING, RH

main58183-95404iBU65..GEN..CBU;BU66..T3..TB..GEN;BU60,61,83,84..(T1,T3)..(GEN,GHD)..(CBU,IV3)199011-199505

TILT CAB

main58183-95404iBU88..LHD..IV3198808-199011

TAIWAN SPEC

main58183-95404iBU65..IV3;BU67,91,96;BU88..T3..(CBU,IV3);BU61,65,66,84..ARL,SA199004-199703

main58183-95405iBU70..BUS;BU88..TW1199007-199703

main58183-95405iBU65..GEN..CBU;BU61..RHD..WT..GEN..IV3199201-199505

HONGKONG SPEC FIXED CAB

main58183-95405iBU91,96..RHD..GEN..IV3199112-199505

W(FIXED SPEC)

main58183-95405iBU88..RHD..GEN..IV3199111-199703

INDIA SPEC;W(FIXED SPEC)

main58183-95405iBU96..RHD..GEN199111-199112

W(FIXED CAB)

main58183-95405iBU88..RHD..GEN..IV3199011-199111

INDIA SPEC

main58183-95405iBU60..ST..IV3;BU61,66..LHD..IV3199004-199011

TAIWAN SPEC

main58183-95406iBU61..GEN;BU88..IV1;BU65..GEN..CBU;BU60,66,83,84,87,94..5F..(ARL,GEN,GHD)198808-199011

main58183-95406iBU88..RHD..GEN..IV3198808-199011

INDIA SPEC

main58183-95407iBU88,91,96..T3..DSL..(CBU,IV3)199008-199011

main58183-95407iBU65..IV3;BU67,91,96;BU88..T3..(CBU,IV3);BU61,65,66,84..ARL,SA198808-199008

W(TILT CAB)

58184BREINFORCEMENT, REAR MOUNTING, LH

main58184-95403iBU65..GEN..CBU;BU66..T3..TB..GEN;BU60,61,83,84..(T1,T3)..(GEN,GHD)..(CBU,IV3)199011-199505

W(TILT CAB)

main58184-95403iBU65..IV3;BU67,91,96..DSL;BU88..T3..(CBU,IV3);BU61,65,66,84..ARL,SA199004-199703

main58184-95403iBU88..LHD..IV3198808-199011

TAIWAN SPEC

main58184-95404iBU61..GEN;BU88..IV1;BU65..GEN..CBU;BU66..T3..TB..GEN;BU60,83,84,87,94..ARL,GEN,GHD199011-199703

main58184-95404iBU88..RHD..GEN..IV3199111-199703

INDIA SPEC OR W(FIXED CAB)

main58184-95404iBU96..RHD..GEN199111-199505

W(FIXED CAB)

main58184-95404iBU88..RHD..GEN..IV3199011-199111

INDIA SPEC

main58184-95404iBU60..ST..IV3;BU61,66..LHD..IV3199004-199011

TAIWAN SPEC

main58184-95405iBU61..GEN;BU88..TW1;BU88..IV1;BU65..GEN..CBU;BU60,66,70,83,84,87,94..5F..(ARL,GEN,GHD)198808-199011

INDIA SPEC

main58184-95406iBU88,91,96..T3..DSL..(CBU,IV3)199008-199011

main58184-95406iBU65..GEN..CBU;BU60,61,66,83,84..(T1,T3)..(GEN,GHD)..(CBU,IV3)198808-199008

W(TILT CAB)

58194ARETAINER, ENGINE COVER HINGE

main58194-95400iBU6#,70,83,84,87198912-199505

AUSTRALIA SPEC

main58194-95400iBU88..RHD..GEN..IV3198912-199703

W(FRONT SEAT BELT=ELR)

58297FREINFORCEMENT, SEAT BELT ANCHOR, NO.2

main58297-95401iBU6#,83,84,88,91,96..LHD198808-199505

main58297-95402iBU61,65..RHD..GEN;BU60,8#,9#..RHD..T3198808-199703

63102APANEL SUB-ASSY, WINDSHIELD HEADER

main63102-95403iBU91,96..TD199004-199109

OWNER CUSTOM SPEC

main63102-95403iBU91,96..TD;BU88..LHD..IV3199109-199505

TAIWAN PACKAGE

main63132-95418iBU6#,70,83,84,87..DMP,TR,V198808-199505

main63132-95420iBU70..BUS198808-199505

W(ROOF VENTILATOR)

main63132-95423iBU88,91,96..CBU,IV3198808-199703

63111PANEL, ROOF

main63100-37020iBU88..TW1199408-199505

W(ROOF VENTILATOR)

main63100-37030iBU88..TW1199408-199505

main63100-92607iBU88..TW1198808-199408

W(ROOF VEVTIRATOR)

main63100-92609iBU88..TW1198808-199408

main63111-37010iBU60..T3;BU61,65,66,67,83,84,87..CBU,IV3199004-199505

main63111-37020iBU65..CBU;BU66..T3..TB;BU60,61,83,84,87..(T1,T3)..(CBU,IV3)199004-199505

W(ROOF VENTILATOR)

main63111-95409iBU60..T3;BU61,65,66,83,84,87..CBU,IV3198808-199004

main63111-95410iBU65..CBU;BU60,61,66,83,84,87..(T1,T3)..(CBU,IV3)198808-199004

W(ROOF VEVTIRATOR)

main63111-95411iBU88,91,96..T3..(CBU,IV3)198808-199703

main63111-95412iBU91,96..TD199004-199109

OWNER CUSTOM SPEC

main63111-95412iBU88..RHD..GEN..IV3198808-199703

INDIA SPEC & W(ROOF VENTIRATOR)

main63111-95412iBU91,96..TD199109-199305

TAIWAN PACKAGE

main63111-95412iBU88..LHD;BU91,96..DSL;BU88..T3..ARL;BU88..RHD..CBU198808-199505

W(ROOF VEVTIRATOR)

main63111-95416iBU60..TW1198808-199505

W(ROOF VEVTIRATOR)

main63111-95417iBU60..TW1198808-199505

main63113-92120iBU70..BUS198808-199505

CENTER REAR

main63113-92605iBU70..V198808-199505

CENTER FRONT

main63113-92605iBU70..V198808-199505

CENTER

main63115-92605iBU70198808-199505

REAR

main63115-92612iBU70..V198808-199505

FRONT

main63115-92613iBU70..V198808-199505

FRONT

main63115-92613iBU70..V198808-199505

W(ROOF VEVTIRATOR),FRONT

63141GREINFORCEMENT, ROOF PANEL, NO.1

main63141-37010iBU60..T3;BU61,65,66,67,83,84,87..CBU,IV3199004-199505

main63141-95403iBU88,91,96..T3..(CBU,IV3)198808-199703

63142REINFORCEMENT, ROOF PANEL, NO.2

main63142-95400iBU65..CBU;BU66..T3..TB;BU60,61,83,84,87..(T1,T3)..(CBU,IV3)198808-199505

63159CSPACER, ROOF REINFORCEMENT

main63159-37010iBU60..ST..IV3;BU61,66..LHD..IV3199004-199505

TAIWAN SPEC

main63159-37010iBU67;BU66..TS;BU66..T2199004-199505

main63159-37020iBU91,96..TD199004-199505

TAIWAN SPEC

64107AFRAME SUB-ASSY, BACK

main64107-37110iBU60..RHD..GEN;BU61,65,66,83,84,87..RHD199309-199505

main64107-37120iBU88..RHD..GEN..IV3199309-199703

W(FRONT SEAT BELT=ELR)

main64107-37120iBU88..T3..ARL199309-199505

AUSTRALIA SPEC

main64107-37130iBU88,91,96..RHD..T3..(CBU,IV3)199309-199703

main64107-37140iBU88,94..IV1199309-199703

INDIA SPEC OR W(FIXED CAB)

main64107-37140iBU91,96..RHD..GEN..IV3199309-199505

FIXED CAB

main64107-37190iBU88..TW1199309-199505

main64107-92623iBU88..TW1198808-199309

main64107-92624iBU70..BUS198808-199505

main64107-92625iBU70..V198808-199505

main64107-92626iBU70..BUS198808-199505

SAUDI ARABIA & GULF SPEC

main64107-95419iBU88,91,96..LHD..DSL198808-199505

main64107-95420iBU88..RHD..GEN..IV3198808-199111

INDIA SPEC

main64107-95420iBU96..RHD..GEN199111-199112

W(FIXED CAB)

main64107-95420iBU91,96..RHD..GEN..IV3199112-199309

FIXED CAB

main64107-95420iBU88,94..IV1198808-199309

main64107-95420iBU88..RHD..GEN..IV3199111-199309

INDIA SPEC OR FIXED CAB

main64107-95421iBU60..TW1..GEN198808-199505

SAUDI ARABIA & GULF SPEC

main64107-95423iBU60..LHD..T3;BU61,66,67,83,84..LHD198808-199505

main64107-95424iBU60..RHD..GEN;BU61,65,66,83,84,87..RHD198808-199309

main64107-95426iBU60..TW1..GEN198808-199505

main64107-95429iBU88,91,96..RHD..T3..(CBU,IV3)198808-199309

main64107-95430iBU65..IV3198808-199505

main64107-95430iBU84..LHD199009-199505

ALGERIA SPEC & W(TILT CAB)

main64107-95433iBU88..RHD..GEN..IV3198808-199309

W(FRONT SEAT BELT=ELR)

main64107-95433iBU88..T3..ARL198910-199309

AUSTRALIA SPEC

main64107-95434iBU91,96..TD199004-199305

main64107-95434iBU88,96..LHD..IV3198808-199505

TAIWAN SPEC

main64107-95435iBU60..ARL198808-199107

64111APANEL, BACK

main64100-37010iBU88,96..LHD..IV3199305-199505

TAIWAN SPEC

main64100-37010iBU91,96..TD199004-199009

OWNER CUSTOM SPEC

main64100-37010iBU91,96..TD;BU88..LHD..IV3199009-199305

TAIWAN PACKAGE

main64100-37120iBU67;BU66..TS;BU66..T2199305-199505

TAIWAN SPEC & W(HEADREST)

main64100-37590iBU88..IV3199606-199703

main64100-95442iBU66..T3..TB..GEN;BU60,61,83,84..LHD..T3198808-199505

main64100-95443iBU84..LHD199009-199505

ALGERIA SPEC

main64100-95443iBU65..IV3198808-199505

main64100-95444iBU60,61,66,83,84..LHD..T3198808-199505

W(HEADREST)

main64100-95444iBU67199004-199305

main64100-95445iBU88,91,96..RHD..T3..(CBU,IV3)198808-199606

main64100-95447iBU60,61,65,83,84,87..RHD..(GEN,GHD,SA)..(CBU,IV3)198808-199505

main64100-95448iBU61,65,66..ARL198808-199505

W(HEADREST)

main64100-95450iBU60..TW1198808-199505

main64100-95451iBU88,91,96..LHD198808-199505

main64101-37010iBU88..TW1199210-199505

main64101-92604iBU88..TW1198808-199210

64122ABAFFLE, DUST REAR BODY

main64122-37030iBU61..ST..(CBU,IV3)199210-199505

main64122-37040iBU83,84..CBU199210-199505

main64122-37050iBU88..TW1;BU88,91,96..CBU199210-199505

main64122-37060iBU60..TW1199210-199505

main64122-37080iBU60,61..T3..CBU199305-199505

main64122-95405iBU60,61,66,83,84,87..T3198808-199210

main64122-95406iBU88,91,96..CBU,IV3198808-199210

main64122-95407iBU61..ST..(CBU,IV3)198808-199210

main64122-95A06iBU60..TW1198808-199210

main65455-93100iBU65..CBU198808-199210

main65455-93102iBU65..CBU199210-199505

64160ACLIP(FOR BACK PANEL UPPER SILENCER)

main90467-06171-C0iBU65,66..ARL199410-199505

BLACK,TRIM1#

64171ABRACKET SUB-ASSY, REAR MOUNTING

main64025-25010iBU65..GEN..CBU;BU66..T3..TB..GEN;BU60,61,83,84,87..(T1,T3)..(GEN,GHD)199107-199402

main64025-25010iBU65..GEN..CBU;BU61..RHD..WT..GEN..IV3199201-199402

HONGKONG SPEC

main64025-25020iBU88..RHD..GEN..IV3199107-199111

INDIA SPEC,RH

main64025-25020iBU70;BU88..TW1199105-199107

main64025-25020iBU96..RHD..GEN199111-199402

W(FIXED CAB),RH

main64025-25020iBU88,94..IV1199107-199402

RH

main64025-25020iBU88..RHD..GEN..IV3199111-199402

INDIA SPEC OR W(FIXED CAB),RH

main64025-95400iBU88,91,96..T3..(CBU,IV3)198808-199703

RH

main64025-95400iBU84..LHD199009-199409

ALGERIA SPEC & W(TILT CAB),RH

main64025-95400iBU65..GEN..CBU;BU66..T3..TB..GEN;BU60,61,83,84..(T1,T3)..(GEN,GHD)..(CBU,IV3)198808-199505

W(TILT CAB)

main64025-95400iBU66..TS;BU66..T2;BU65,67..IV3;BU65,66,84..ARL,SA199409-199505

main64026-95400iBU88,91,96..T3..(CBU,IV3)198808-199703

LH

main64026-95401iBU88..RHD..GEN..IV3198808-199111

INDIA SPEC,LH

main64026-95401iBU96..RHD..GEN199111-199505

W(FIXED CAB),LH

main64026-95401iBU88..RHD..GEN..IV3199111-199703

INDIA SPEC OR W(FIXED CAB),LH

main64026-95401iBU88,94..IV1198808-199703

LH

main64026-95402iBU84..LHD199009-199409

ALGERIA SPEC & W(TILT CAB),LH

main64026-95402iBU65..IV3198808-199409

LH

main64171-95408iBU65..GEN..CBU;BU66..T3..TB..GEN;BU60,61,83,84,87..(T1,T3)..(GEN,GHD)199402-199505

HONGKONG SPEC

main64171-95408iBU65..GEN..CBU;BU60,61,66,83,84,87..(T1,T3)..(GEN,GHD)198808-199107

main64171-95410iBU88..RHD..GEN..IV3198808-199703

RH

main64171-95410iBU88..RHD..GEN..IV3199402-199703

INDIA SPEC OR W(FIXED CAB),RH

main64171-95410iBU60..TW1198808-199107

main64171-95410iBU88..RHD..GEN..IV3198808-199107

INDIA SPEC,RH

main64171-95410iBU91,96..RHD..GEN..IV3199402-199505

W(FIXED CAB),RH

64186RETAINER, REAR MOUNTING BRACKET

main64186-95A00iBU60..ST..IV3;BU61,66..LHD..IV3199104-199505

TAIWAN SPEC

main64186-95A00iBU60,88..TW1..ARL198808-199505

main64186-95A00iBU65..GEN..CBU;BU61..RHD..WT..GEN..IV3199201-199505

HONGKONG SPEC

64189CLAMP, BACK PANEL SILENCER

main64189-95400iBU91,96..TD198808-199505

64190SILENCER ASSY, BACK PANEL

main64190-95400iBU61,65,66..ARL198808-199505

main64190-95406iBU88,91..T3..ARL198808-199505

main64190-95408iBU88,96..LHD..IV3199305-199505

TAIWAN SPEC

main64190-95408iBU91,96..TD199004-199110

OWNER CUSTOM SPEC

main64190-95408iBU91,96..TD;BU88..LHD..IV3199110-199305

TAIWAN PACKAGE

64192ABOARD, BACK PANEL SILENCER, UPPER

main64192-37010-06iBU91,96..TD199004-199109

BROWN,TRIM4#

main64192-37010-B0iBU91,96..TD199109-199505

GRAY,TRIM1#

64270DTRIM ASSY, BACK PANEL

main64270-37010-06iBU91,96..TD199004-199109

BROWN,TRIM4#,RH

main64270-37010-B0iBU91,96..TD;BU88..LHD..IV3199110-199305

TAIWAN PACKAGE,GRAY,TRIM1#,RH

main64270-37010-B0iBU91,96..TD199109-199110

GRAY,TRIM1#,RH

main64270-37010-B0iBU88,96..LHD..IV3199305-199505

TAIWAN SPEC,GRAY,TRIM1#,RH

main64270-37020-06iBU91,96..TD199004-199109

BROWN,TRIM4#,LH

main64270-37020-B0iBU91,96..TD;BU88..LHD..IV3199110-199305

TAIWAN PACKAGE,GRAY,TRIM1#,LH

main64270-37020-B0iBU88,96..LHD..IV3199305-199505

TAIWAN SPEC,GRAY,TRIM1#,LH

main64270-37020-B0iBU91,96..TD199109-199110

GRAY,TRIM1#,LH

64270ECLIP

main90467-07054-13iBU91,96..TD;BU88..LHD..IV3199109-199505

GRAY,TRIM1#

main90467-07054-16iBU91,96..TD199004-199109

BROWN,TRIM4#

64811GLASS, BACK WINDOW

main64811-37020iBU65..GEN..CBU;BU66..T3..TB..GEN;BU60,61,83,84,87..(T1,T3)..(GEN,GHD)..(CBU,IV3)199109-199505

*TEM,T=3.5,BRONZE

main64811-37040iBU88,91,96..DSL..GEN..(CBU,IV3)199109-199703

*TEM,T=3.5,BRONZE

main64811-37050iBU91,96..TD;BU88..LHD..IV3199109-199305

*TT,T=4.0,TAIWAN PACKAGE

main64811-95409iBU60..T3;BU61,65,66,67,83,84,87..CBU,IV3198808-199505

*TEM,T=3.5

main64811-95410iBU60..TW1;BU88,91,96..CBU,IV3198808-199703

*TEM,T=3.5

main64812-95402iBU91,96..TD199004-199109

*TEM,T=4.0,OWNER CUSTOM SPEC

64813GLASS, BACK WINDOW CORNER, RH

main64814-37010iBU91,96..TD;BU88..LHD..IV3199109-199305

*TT,T=4.0,TAIWAN PACKAGE

main64814-95400iBU91,96..TD199004-199109

*TEM,T=4.0,OWNER CUSTOM SPEC

64814GLASS, BACK WINDOW CORNER, LH

main64814-37010iBU91,96..TD;BU88..LHD..IV3199109-199305

*TT,T=4.0,TAIWAN PACKAGE

main64814-95400iBU91,96..TD199004-199109

*TEM,T=4.0,OWNER CUSTOM SPEC

64831WEATHERSTRIP, BACK WINDOW GLASS

main64831-95406iBU6#,8#,91,96..CBU,IV3198808-199703

64831AWEATHERSTRIP, BACK WINDOW GLASS, UPPER

main64831-95404iBU91,96..TD199004-199109

main64831-95404iBU91,96..TD;BU88..LHD..IV3199109-199305

TAIWAN PACKAGE

64832KEY, BACK WINDOW WEATHERSTRIP

main64832-95010iBU60..T3;BU61,65,66,67,83,84,87..CBU,IV3198808-199505

main64832-95013iBU60..TW1;BU88,91,96..CBU,IV3198808-199703

64832AWEATHERSTRIP, BACK WINDOW VERTICAL

main64832-95400iBU91,96..TD199004-199012

OWNER CUSTOM SPEC

main64834-37010iBU91,96..TD199012-199109

OWNER CUSTOM SPEC

main64834-37010iBU91,96..TD;BU88..LHD..IV3199109-199305

TAIWAN PACKAGE

64833AWEATHERSTRIP, BACK WINDOW CENTER CHANNEL

main64833-95400iBU91,96..TD199004-199305

NO.1

main64833-95401iBU91,96..TD199004-199305

NO.2

64834CWEATHERSTRIP, BACK WINDOW GLASS, LOWER

main64834-95400iBU91,96..TD199004-199305

64835AWEATHERSTRIP, BACK WINDOW GLASS, CENTER

main64835-37010iBU91,96..TD;BU88..LHD..IV3199012-199305

64837CWEATHERSTRIP, BACK WINDOW CORNER GLASS

main64837-95400iBU91,96..TD199004-199305

64839APACKING, BACK WINDOW

main64839-89101iBU91,96..TD199004-199305

64851STOP, BACK WINDOW SLIDE GLASS

main64851-95400iBU91,96..TD199004-199305

64882FRAME, BACK WINDOW VERTICAL

main64882-95400iBU91,96..TD199004-199305

64883FRAME, BACK WINDOW

main64881-95400iBU91,96..TD199004-199305

64883ACHANNEL, BACK WINDOW SLIDE

main64883-95400iBU91,96..TD199004-199305

69370ALOCK ASSY, BACK WINDOW

main69370-89101iBU91,96..TD199004-199305

69374CATCH, BACK WINDOW LOCK

main69374-89101iBU91,96..TD;BU88..LHD..IV3199004-199305

69375ARETAINER, BACK WINDOW LOCK

main69375-89102iBU91,96..TD;BU88..LHD..IV3199004-199305

69376BPACKING, BACK WINDOW LOCK

main69376-89101iBU91,96..TD199004-199305

6777295J01WEATHERSTRIP, BACK DOOR TRIM, LH

main67772-95J01

9015950206

main90159-50206

9033325001

main90333-25001

9046708033

main90467-08033

9324923008

main93249-23008

9352054010

main93520-54010

9354024012

main93540-24012

9356015010

main93560-15010

50 parts on this diagram · 3 diagrams in section
