Toyota DUET — SWITCH & RELAY & COMPUTER

0001 1 0002 1 0003 1 0004 1 0005 1 0006 1 0007 1 0008 1

1104

1106

13830BVALVE ASSY, OIL CONTROL

main13830-97201iM100,110200005

1703

4502

83320GAGE ASSY, FUEL SENDER

main77501-97201iM10#199809

main77501-97202iM11#199809

83530SWITCH ASSY, OIL PRESSURE (FOR ENGINE)

main83530-87205iM100,110200012-200209

sub83530-97202

main83530-97201iM100,110200210

sub83530-97202

main83530-97401iM101,111200101

84210SWITCH ASSY, BACK-UP LAMP

main84210-97201iM10#,11#..5F199809

84210BGASKET, BACK-UP LAMP SWITCH

main90044-30178iM10#,11#..5F199809

84540SWITCH ASSY, NEUTRAL START

main84540-97201iM10#,11#..4AT199809-200108

main84540-97203iM10#,11#..ATM200109

sub84540-B1020

89421BSENSOR, VACUUM

main89421-97401iM101,111200005

sub89421-B1010

89422ASENSOR, WATER TEMPERATURE

main89422-16010iM101,111200005

main89422-87204iM100,110199809

89424BSWITCH, INLET AIR TEMPERATURE

main89424-87202iM100,110199809

main89424-87703iM101,111200005

89437COVER, SENSOR

main89437-97203iM10#,11#200005

89438SWITCH, POWER STEERING OIL PRESSURE

main89630-97201iM10#,11#199809

89439BRACKET, SENSOR

main89439-97201iM100,110200005-200112

main89439-97207iM100,110200112

main89439-97401iM101,111200005

main89439-97403iM101,111..V,X200112

89465SENSOR, OXYGEN

main89465-87212iM100,110199809-200005

main89465-97205iM100,110200005

main89465-97212iM100,110200112

main89465-97403iM100,110200005-200112

main89465-97404iM101,111200005

main89465-97405iM101,111200005-200112

main89465-97410iM101,111200112

89615SENSOR, KNOCK CONTROL

main89615-97201iM100,110199809

main89615-97401iM101,111200005

9004301262

main90043-01262

9004430279

main90044-30279

9004430280

main90044-30280

9004430293

main90044-30293

9043012221

main90430-12221

9162160614

main91621-60614

91621B0816

main91621-B0816

91621J0612

main91621-J0612

26 parts on this diagram · 8 diagrams in section
