Toyota DUET — FLOOR PAN & LOWER BACK PANEL

0001 1 0002 1

5305

58111PAN, FRONT FLOOR

main58111-97201iM10#199809

main58111-97202iM11#199809

main58111-97203iM101..ATM200005

58111NPLUG, HOLE(FOR FRONT FLOOR)

main90048-71116×4iM100,110199809-200005

58301CPLUG, HOLE(FOR REAR FLOOR NO.1)

main90048-71141iM10#,11#199809-200112

58301DPLUG, HOLE(FOR REAR FLOOR NO.2)

main90048-71099×2iM10#,11#199809-200112

main90048-71292×2iM10#,11#200112

58308PANEL SUB-ASSY, BODY LOWER BACK, INNER

main58308-97201iM10#,11#199809

sub58308-97202

58308ECOVER, HOLE(FOR LOWER BACK)

main90048-74004×2iM100,110199809-200005

58308FPLUG, HOLE(FOR LOWER BACK)

main90048-74029×3iM100,110199809-200005

58311APLUG, HOLE(FOR FLOOR PAN)

main90048-71151iM100,110..V199809

6101

6102

7601

9004874042

main90048-74042

13 parts on this diagram · 2 diagrams in section
