Toyota CROWN — FRONT CLEARANCE LAMP
81610LAMP ASSY, PARKING & CLEARANCE, RH
81610BBULB(FOR PARKING & CLEARANCE LAMP)
12V 5W,12V 5W,NO.1
12V 5W,12V 5W,NO.2
81611LENS, PARKING & CLEARANCE LAMP, RH
81614GASKET, PARKING AND CLEARANCE LAMP BODY, RH
81614AGASKET, PARKING AND CLEARANCE LAMP BODY, NO.1 RH
81618BRACKET, PARKING AND CLEARANCE LAMP, RH
N0.1
N0.2
81620LAMP ASSY, PARKING & CLEARANCE, LH
81621LENS, PARKING & CLEARANCE LAMP, LH
81624GASKET, PARKING AND CLEARANCE LAMP BODY, LH
81624AGASKET, PARKING AND CLEARANCE LAMP BODY, NO.1 LH
81625SOCKET AND WIRE, PARKING AND CLEARANCE LAMP
81628BRACKET, PARKING AND CLEARANCE LAMP, LH
N0.1
N0.2
8127995700WASHER, SIDE TURN SIGNAL LAMP
main81279-95700
9018904022
main90189-04022
9354054014
main93540-54014
9354054035
main93540-54035
16 parts on this diagram · 4 diagrams in section
FRONT CLEARANCE LAMP for Toyota CROWN
This section contains 29 genuine Toyota parts for the FRONT CLEARANCE LAMP system of the Toyota CROWN. Key components include: LAMP ASSY, PARKING & CLEARANCE, RH, BULB(FOR PARKING & CLEARANCE LAMP), COVER ASSY, CLEARANCE LAMP, RH, LENS, PARKING & CLEARANCE LAMP, RH, COVER, CLEARANCE LAMP LENS, RH.
