Toyota CROWN — CAUTION PLATE & NAME PLATE (ENGINE)

11291PLATE, ENGINE NAME

main11291-43020i5ME..MS112197909-198307

main11291-43030i5M..MS112198008-198307

main11291-45040i4M..MS111197909-198008

11293PLATE, ENGINE CAUTION & ENGINE NAME

main11293-44061i5R..RS110197909-198307

main11293-54010iL..LS110197909-198307

11296PLATE, TIMING BELT CAUTION

main11296-54010iL..LS110198004-198307

17627PLATE, AIR PUMP CAUTION, NO.1

main90917-07066i4M,5ME..MS11#..ARL197909-198307

17700CPLATE, AIR CLEANER CAUTION (FOR ENGINE MODEL)

main90917-07053iL,5R..LS110,RS110197909-197910

main90917-07057i5R..RS110..LHD..BTP..GEN197909-198307

TAXI SPEC

main90917-07079i5R..RS110197910-198010

sub90917-07087

main90917-07081iL..LS110197910-198108

main90917-07084i5R..RS110198010-198307

main90917-07088iL..LS110198108-198307

17700DPLATE, ENGINE CAUTION

main11293-43030i5ME..MS112..ARL198008-198108

main11293-43031i5ME..MS112..ARL198108-198204

main11293-45050i4M..MS111197909-198008

17792PLATE, ENGINE VACUUM HOSE INFORMATION

main17792-43020i5ME..MS112..ARL198008-198208

main17792-43021i5ME..MS112..ARL198208-198307

SWITZERLAND SPEC

main17792-45072i4M..MS111..ARL197909-198008

23923PLATE, FUEL SEDIMENTER CAUTION

main23923-54010iL..LS110..GEN198008-198307

8 parts on this diagram · 1 diagram in section
