Toyota CROWN — BACK UP LAMP

81670LAMP ASSY, BACK-UP, RH

main81670-39065i197501-197908

81670BBULB(FOR BACK-UP LAMP)

main99132-11210×2i197501-197908

12V 21W,12V 21W

81674GASKET, BACK-UP LAMP BODY, RH

main81674-31020i197501-197908

81675SOCKET & WIRE, BACK-UP LAMP

main81675-31030×2i197501-197908

81680LAMP ASSY, BACK UP, LH

main81670-39065i197501-197908

81684GASKET, BACK UP LAMP BODY, LH

main81674-31020i197501-197908

9016850002

main90168-50002

7 parts on this diagram · 1 diagram in section

BACK UP LAMP for Toyota CROWN

This section contains 7 genuine Toyota parts for the BACK UP LAMP system of the Toyota CROWN. Key components include: LAMP ASSY, BACK-UP, RH, BULB(FOR BACK-UP LAMP), GASKET, BACK-UP LAMP BODY, RH, SOCKET & WIRE, BACK-UP LAMP, LAMP ASSY, BACK UP, LH.
