Toyota CRESTA — TRACTION CONTROL
4702BRAKE MASTER CYLINDER
84580CSWITCH ASSY, THROTTLE POSITION
84580DBULB, THROTTLE POSITION SWITCH
84580HCAP, THROTTLE POSITION SWITCH BULB
84988SWITCH, TRACTION CONTROL
84988ABULB, TRACTION CONTROL SWITCH
84988BCAP, TRACTION CONTROL SWICH BULB
89632MOTOR, TRACTION THROTTLE VALVE
89634BRACKET, TRACTION CONTROL COMPUTER
89637SENSOR, OIL PRESSURE
89670BRELAY, THROTTLE CONTROL
89671COMPUTER, THROTTLE CONTROL
89672MOTOR, THROTTLE CONTROL
89677BRACKET, THROTTLE CONTROL COMPUTER, NO.1
89678BRACKET, THROTTLE CONTROL COMPUTER, NO.2
9017906009
main90179-06009
9331915010
main93319-15010
17 parts on this diagram · 2 diagrams in section
TRACTION CONTROL for Toyota CRESTA
This section contains 17 genuine Toyota parts for the TRACTION CONTROL system of the Toyota CRESTA. Key components include: BRAKE MASTER CYLINDER, SWITCH ASSY, THROTTLE POSITION, BULB, THROTTLE POSITION SWITCH, CAP, THROTTLE POSITION SWITCH BULB, SWITCH, TRACTION CONTROL.
