Toyota CRESSIDA — CAUTION PLATE & NAME PLATE (ENGINE)

11289PLATE, SPARK PLUG CAUTION

main11289-13040i198208-198407

11291PLATE, ENGINE NAME

main11291-43020i198009-198208

11294PLATE, ENGINE CAUTION, NO.2

main11294-34020i198009-198208

11298PLATE, EMISSION CONTROL INFORMATION

main11298-43010i198009-198108

main11298-43030i198009-198108

CALIFORNIA SPEC

main11298-43070i198108-198208

CALIFORNIA SPEC

main11298-43090i198108-198208

main11298-43100i198208-198308

main11298-43110i198208-198308

CALIFORNIA SPEC

main11298-43130i198308-198407

CALIFORNIA SPEC

main11298-43140i198308-198407

17700DPLATE, ENGINE CAUTION

main11293-28040i198009-198407

17792PLATE, ENGINE VACUUM HOSE INFORMATION

main17792-43010i198009-198208

main17792-43080i198208-198308

main17792-43120i198308-198407

6 parts on this diagram · 1 diagram in section

CAUTION PLATE & NAME PLATE (ENGINE) for Toyota CRESSIDA

This section contains 6 genuine Toyota parts for the CAUTION PLATE & NAME PLATE (ENGINE) system of the Toyota CRESSIDA. Key components include: PLATE, SPARK PLUG CAUTION, PLATE, ENGINE NAME, PLATE, ENGINE CAUTION, NO.2, PLATE, EMISSION CONTROL INFORMATION, PLATE, ENGINE CAUTION.
