Toyota COROLLA — CAUTION PLATE & NAME PLATE (ENGINE)

Parts diagram

11291PLATE, ENGINE NAME

main11291-16010i198208-198303

4A-C

main11291-16020i198303-198307

4A

main11291-28040i197908-198208

3T-C

11294PLATE, ENGINE CAUTION, NO.2

main11294-34020i197908-198208

17627PLATE, AIR PUMP CAUTION, NO.1

main90917-07066i197908-198008

CALIFORNIA SPEC

17700DPLATE, ENGINE CAUTION

main11293-16010i198208-198307

main11293-28040i197908-198208

17792PLATE, ENGINE VACUUM HOSE INFORMATION

main17792-15150i198208-198307

main17792-15160i198208-198307

CALIFORNIA SPEC

main17792-15170i198208-198307

HIGH ALTITUDE SPEC

main17792-15180i198208-198307

main17792-15210i198208-198307

FOR AFTER VEHICLE DELIVERY

main17792-28020i197908-198008

main17792-28030i197908-198008

CALIFORNIA SPEC

main17792-28040i197908-198008

main17792-28041i198008-198208

main17792-28070i198008-198108

main17792-28080i198008-198208

CALIFORNIA SPEC

main17792-28090i198008-198208

CALIFORNIA SPEC

main17792-28110i198108-198208

5 parts on this diagram · 1 diagram in section
