Toyota COROLLASPEAKER

Parts diagram
6404DECK BOARD & DECK TRIM COVER
86160SPEAKER ASSY, FRONT NO.1
main86160-12170i198305-198704
AM/FM MULTIPLEX OR TAPE PLAYER
main86160-12170i198305-198704
AM
86160ASPEAKER SET, FRONT
main86160-19665i198305-198704
RH
86160BSPEAKER ASSY, REAR
main86160-12100i198305-198704
RH
main86160-12110i198305-198704
RH
main86160-12120i198305-198704
LH
main86160-12180i198305-198704
LH
main86160-12190i198410-198704
RH
main86160-12200i198410-198704
LH
86160CSPEAKER SET, REAR
main86160-19675i198305-198704
main86160-19695i198305-198704
main86160-19855i198410-198704
GRAY
main86160-19865i198410-198704
BROWN
86202WIRE, SPEAKER, NO.1
main86203-12140i198305-198704
main86203-12150i198305-198704
86219DBRACKET, SPEAKER, REAR NO.1
main86219-12070i198410-198704
9018305005
9356055016
9356855014

10 parts on this diagram · 2 diagrams in section

SPEAKER for Toyota COROLLA

This section contains 13 genuine Toyota parts for the SPEAKER system of the Toyota COROLLA. Key components include: DECK BOARD & DECK TRIM COVER, SPEAKER ASSY, FRONT NO.1, SPEAKER SET, FRONT, SPEAKER ASSY, REAR, SPEAKER SET, REAR.
