Toyota COROLLA — BODY STRIPE

75981STRIPE, FRONT FENDER, RH NO.1

main75981-12210i197903-198102

main75981-12211i198102-198108

main75981-12240i197903-198108

BLACK

main75981-12260i198005-198108

TWO TONE,MAROON

main75981-12270i198007-198007

COROLLA UNIVERSAL

main75981-12330i198108-198304

main75981-12340i198108-198304

main75981-12350i198108-198304

main75981-12360i198108-198304

main75981-12400i198108-198304

APEX

main75981-12410i198108-198304

main75981-12946i197903-198108

ORANGE

main75981-13030-04i198205-198308

WHITE & BLUE,BLUE

main75981-13030-08i198205-198308

GOLD & WHITE,IVORY

main75981-13040i198308-198508

main75981-13050i198508-198707

75982STRIPE, FRONT FENDER, LH NO.1

main75981-13030-04i198205-198308

WHITE & BLUE,BLUE

main75981-13030-08i198205-198308

GOLD & WHITE,IVORY

main75982-12210i197903-198102

main75982-12211i198102-198108

main75982-12240i197903-198108

BLACK

main75982-12260i198005-198108

TWO TONE,MAROON

main75982-12270i198007-198007

COROLLA UNIVERSAL

main75982-12330i198108-198304

main75982-12340i198108-198304

main75982-12350i198108-198304

main75982-12360i198108-198304

main75982-12400i198108-198304

APEX

main75982-12410i198108-198304

main75982-12901i197903-198108

ORANGE

main75982-13040i198308-198508

main75982-13050i198508-198707

75983STRIPE, FRONT FENDER, RH NO.2

main75983-12140i197903-198102

main75983-12141i198102-198108

main75983-12150i197903-198108

BLACK

main75983-12160i198007-198007

COROLLA UNIVERSAL

main75983-12220i198108-198304

main75983-12230i198108-198304

main75983-12240i198108-198304

main75983-12250i198108-198304

main75983-12260i198108-198304

main75983-12270i198108-198304

main75983-12290i198108-198304

APEX

main75983-12900i197903-198108

ORANGE

main75983-13020i198308-198508

main75983-13030i198508-198707

75984STRIPE, FRONT FENDER, LH NO.2

main75984-12140i197903-198102

main75984-12141i198102-198108

main75984-12150i197903-198108

BLACK

main75984-12160i198007-198007

COROLLA UNIVERSAL

main75984-12220i198108-198304

main75984-12230i198108-198304

main75984-12240i198108-198304

main75984-12250i198108-198304

main75984-12260i198108-198304

main75984-12270i198108-198304

main75984-12290i198108-198304

APEX

main75984-12900i197903-198108

ORANGE

main75984-13020i198308-198508

main75984-13030i198508-198707

75985STRIPE, FRONT DOOR, RH

main75981-13030-04i198205-198308

WHITE & BLUE,BLUE

main75981-13030-08i198205-198308

GOLD & WHITE,IVORY

main75985-12130i197903-198102

main75985-12131i198102-198108

main75985-12140i197903-198108

BLACK

main75985-12150i198005-198108

TWO TONE,MAROON

main75985-12160i198007-198007

COROLLA UNIVERSAL

main75985-12220i198108-198304

main75985-12230i198108-198304

main75985-12240i198108-198304

main75985-12250i198108-198304

main75985-12260i198108-198304

main75985-12270i198108-198304

main75985-12290i198108-198304

APEX

main75985-12900i197903-198108

ORANGE

main75985-13050i198308-198508

main75985-13060i198508-198707

75986STRIPE, FRONT DOOR, LH

main75981-13030-04i198205-198308

WHITE & BLUE,BLUE

main75981-13030-08i198205-198308

GOLD & WHITE,IVORY

main75985-12130i197903-198102

main75985-12131i198102-198108

main75985-13050i198308-198508

main75985-13060i198508-198707

main75986-12130i197903-198108

BLACK

main75986-12140i198005-198108

TWO TONE,MAROON

main75986-12150i198007-198007

COROLLA UNIVERSAL

main75986-12210i198108-198304

main75986-12220i198108-198304

main75986-12230i198108-198304

main75986-12240i198108-198304

main75986-12250i198108-198304

main75986-12260i198108-198304

main75986-12280i198108-198304

APEX

main75986-12900i197903-198108

ORANGE

75987STRIPE, REAR DOOR, RH

main75981-13030-04i198205-198308

WHITE & BLUE,BLUE

main75981-13030-08i198205-198308

GOLD & WHITE,IVORY

main75987-12070i197903-198102

DOHC EFI

main75987-12072i198102-198108

DOHC EFI

main75987-12080i198007-198007

COROLLA UNIVERSAL

main75987-12100i198108-198304

main75987-12110i198108-198304

main75987-12120i198103-198108

TWIN CAM

main75987-13040i198308-198508

main75987-13050i198508-198707

75988STRIPE, REAR DOOR, LH

main75981-13030-04i198205-198308

WHITE & BLUE,BLUE

main75981-13030-08i198205-198308

GOLD & WHITE,IVORY

main75988-12070i197903-198102

DOHC EFI

main75988-12072i198102-198108

DOHC EFI

main75988-12080i198007-198007

COROLLA UNIVERSAL

main75988-12100i198108-198304

main75988-12110i198108-198304

main75988-12120i198103-198108

TWIN CAM

main75988-13040i198308-198508

main75988-13050i198508-198707

75991STRIPE, QUARTER, RH NO.1

main75981-13030-04i198205-198308

WHITE & BLUE,BLUE

main75981-13030-08i198205-198308

GOLD & WHITE,IVORY

main75991-12150i197903-198102

main75991-12151i198102-198108

main75991-12170i197903-198102

BLACK & WHITE (DOHC EFI)

main75991-12172i198102-198108

BLACK & WHITE (DOHC EFI)

main75991-12200i198005-198108

TWO TONE,MAROON

main75991-12210i198011-198102

ORANGE & BLACK(DOHC EFI)

main75991-12211i198102-198108

ORANGE & BLACK(DOHC EFI)

main75991-12230i198007-198007

COROLLA UNIVERSAL

main75991-12290i198108-198304

main75991-12310i198108-198304

main75991-12320i198108-198304

main75991-12330i198108-198304

APEX

main75991-12340i198103-198108

BLACK & WHITE (TWIN CAM)

main75991-12350i198103-198108

ORANGE & BLACK (TWIN CAM)

main75991-12360i198108-198304

main75991-12370i198108-198304

main75991-12900i197903-198011

ORANGE & BLACK(DOHC EFI)

main75991-13050i198308-198508

main75991-13060i198508-198707

75992STRIPE, QUARTER, LH NO.1

main75981-13030-04i198205-198308

WHITE & BLUE,BLUE

main75981-13030-08i198205-198308

GOLD & WHITE,IVORY

main75992-12140i197903-198102

main75992-12141i198102-198108

main75992-12160i197903-198102

BLACK & WHITE (DOHC EFI)

main75992-12162i198102-198108

BLACK & WHITE (DOHC EFI)

main75992-12190i198005-198108

TWO TONE,MAROON

main75992-12200i198011-198102

ORANGE & BLACK(DOHC EFI)

main75992-12201i198102-198108

ORANGE & BLACK(DOHC EFI)

main75992-12220i198007-198007

COROLLA UNIVERSAL

main75992-12280i198108-198304

main75992-12300i198108-198304

main75992-12310i198108-198304

main75992-12320i198108-198304

APEX

main75992-12330i198103-198108

BLACK & WHITE (TWIN CAM)

main75992-12340i198103-198108

ORANGE & BLACK (TWIN CAM)

main75992-12350i198108-198304

main75992-12360i198108-198304

main75992-12900i197903-198011

ORANGE & BLACK(DOHC EFI)

main75992-13050i198308-198508

main75992-13060i198508-198707

75993STRIPE, QUARTER, RH NO.2

main75993-12080i197903-198108

BLACK

main75993-12160i198108-198304

main75993-12170i198108-198304

main75993-12180i198108-198304

main75993-12190i198108-198304

main75993-12210i198108-198304

APEX

main75993-12900i197903-198108

ORANGE

main75993-13020i198508-198707

75994STRIPE, QUARTER, LH NO.2

main75994-12080i197903-198108

BLACK

main75994-12160i198108-198304

main75994-12170i198108-198304

main75994-12180i198108-198304

main75994-12190i198108-198304

main75994-12210i198108-198304

APEX

main75994-12900i197903-198108

ORANGE

main75994-13010i198508-198707

12 parts on this diagram · 6 diagrams in section

BODY STRIPE for Toyota COROLLA

This section contains 21 genuine Toyota parts for the BODY STRIPE system of the Toyota COROLLA. Key components include: STRIPE, BACK DOOR, STRIPE, BACK DOOR, UPPER RH, STRIPE, BACK DOOR, UPPER LH, STRIPE, BACK DOOR, LOWER RH, STRIPE, BACK DOOR, LOWER LH.
