Toyota COROLLA — BACK UP LAMP

81670BBULB(FOR BACK-UP LAMP)

main90981-11039×2i199705-199811

main90981-11059×2i199811

81671LENS, BACK-UP LAMP, RH

main81671-13040i199705

81672GASKET, BACK-UP LAMP LENS, RH

main81672-13040i199705

81675SOCKET & WIRE, BACK-UP LAMP

main81675-13040×2i199705

81681LENS, BACK-UP LAMP, LH

main81681-13010i199705

81682GASKET, BACK UP LAMP LENS, LH

main81682-13010i199705

9007599124

main90075-99124

9017905011

main90179-05011

8 parts on this diagram · 1 diagram in section

BACK UP LAMP for Toyota COROLLA

This section contains 8 genuine Toyota parts for the BACK UP LAMP system of the Toyota COROLLA. Key components include: BULB(FOR BACK-UP LAMP), LENS, BACK-UP LAMP, RH, GASKET, BACK-UP LAMP LENS, RH, SOCKET & WIRE, BACK-UP LAMP, LENS, BACK-UP LAMP, LH.
