Toyota COROLLA SPRINTER — DISC WHEEL & WHEEL CAP

42601WHEEL, DISC

main42611-1A140-01×4i199402-199605

14X5.5J,TYPE A:REFER TO ILLUSTRATION,BLACK

main42611-1A180×4i199402-199605

14X5.5JJ,TYPE B:REFER TO ILLUSTRATION;W(ALUMINUM WHEEL)

42601AWHEEL, DISC (FOR SPARE)

main42611-1A140-01i199402-199605

14X5.5J,TYPE A:REFER TO ILLUSTRATION,BLACK

main42611-1A180i199402-199605

14X5.5JJ,TYPE B:REFER TO ILLUSTRATION;W(ALUMINUM WHEEL)

42601CNUT, HUB (FOR AXLE)

main90942-01007×16i199402-199605

main90942-01062×16i199402-199605

W(ALUMINUM WHEEL)

42603ORNAMENT SUB-ASSY, WHEEL HUB

main42603-12610×4i199402-199605

TYPE A:REFER TO ILLUSTRATION

42611GVALVE (FOR TUBELESS TIRE)

main90942-05009×4i199402-199605

42611JVALVE (FOR TUBELESS TIRE SPARE)

main90942-05009i199402-199605

42621CAP, WHEEL

main42602-02040×4i199402-199605

TYPE A:REFER TO ILLUSTRATION

main42602-12230×4i199402-199605

TYPE B:REFER TO ILLUSTRATION

42652TIRE

main42652-1A150×4i199402-199605

185/60R14 82H

42652ATIRE (FOR SPARE)

main42652-1A150i199402-199605

185/60R14 82H

9 parts on this diagram · 2 diagrams in section

DISC WHEEL & WHEEL CAP for Toyota COROLLA SPRINTER

This section contains 54 genuine Toyota parts for the DISC WHEEL & WHEEL CAP system of the Toyota COROLLA SPRINTER. Key components include: WHEEL, DISC, WHEEL, DISC (FOR SPARE), NUT, HUB (FOR AXLE), ORNAMENT SUB-ASSY, WHEEL HUB, VALVE (FOR TUBELESS TIRE).
