Toyota COROLLA SPACIO — INTERIOR LAMP

81205BBULB, ASH RECEPTACLE LAMP

main90981-11018i200304-200706

81240LAMP ASSY, ROOM, NO.1

main81240-12070-A0i200105-200304

IVORY,TRIM0#

main81240-12070-B0i200304-200305

81240BBULB, ROOM LAMP, NO.1

main90981-14011i200105-200304

81240DLAMP ASSY, ROOM, NO.2

main81240-52010-A0i200105-200304

IVORY,TRIM0#

main81240-52010-B0i200105-200304

LT.GRAY,TRIM1#

81240EBULB, ROOM LAMP, NO.2

main90981-14011i200105-200304

81241LENS, ROOM LAMP, NO.1

main81241-12070i200304

81241ALENS, ROOM LAMP, NO.2

main81241-44010i200304

81260ALAMP ASSY, MAP

main81260-13030-A0i200105-200208

IVORY,TRIM0#

main81260-13030-B0i200105-200208

LT.GRAY,TRIM1#

main81260-13031-A0i200304-200706

IVORY,TRIM0#

main81260-13031-B0i200304-200706

LT.GRAY,TRIM1#

main81260-14080-A2i200105-200304

main81260-14080-B6i200111-200304

81260CBULB(FOR MAP LAMP)

main90981-12005×2i200105-200304

81870DLAMP ASSY, KEY CYLINDER

main81870-13010i200105-200304

81870EBULB, KEY CYLINDER LAMP

main90010-01056i200105-200304

8202WIRING & CLAMP

→ Go to FIG 82-02

8424ANTI-THEFT DEVICE

→ Go to FIG 84-24

9016040021

main90160-40021

9046804157

main90468-04157

9354014516

main93540-14516

9354054014

main93540-54014

17 parts on this diagram · 1 diagram in section

INTERIOR LAMP for Toyota COROLLA SPACIO

This section contains 17 genuine Toyota parts for the INTERIOR LAMP system of the Toyota COROLLA SPACIO. Key components include: BULB, ASH RECEPTACLE LAMP, LAMP ASSY, ROOM, NO.1, BULB, ROOM LAMP, NO.1, LAMP ASSY, ROOM, NO.2, BULB, ROOM LAMP, NO.2.
