Toyota COROLLA SED/WG (JPP) — DISC WHEEL & WHEEL CAP

0001 1 0002 1 0003 1

42601WHEEL, DISC

main42611-1A450iZZE120..JPP..TERRA200110-200405

14X5.5JJ, #,TYPE A:REFER TO ILLUSTRATION

main42611-1A480iNDE120,ZZE12#..JPP200110-200405

15X6JJ, #,TYPE A:REFER TO ILLUSTRATION

main42611-1A510iNDE120,ZZE12#..JPP200110-200405

15X6JJ, #,TYPE C:REFER TO ILLUSTRATION

42601AWHEEL, DISC (FOR SPARE)

main42611-1A450iZZE120..JPP..TERRA200110-200405

14X5.5JJ, #,TYPE A:REFER TO ILLUSTRATION

main42611-1A480iNDE120,ZZE12#..JPP200110-200405

15X6JJ, #,TYPE A:REFER TO ILLUSTRATION

42601CNUT, HUB (FOR AXLE)

main90942-01007iZZE12#..JPP..SED200110-200405

TYPE A:REFER TO ILLUSTRATION

main90942-01058iZZE12#..JPP..SED200110-200405

TYPE B:REFER TO ILLUSTRATION

main90942-01058iNDE120,ZZE12#..JPP200405

TYPE B:REFER ILLUST.

42611GVALVE (FOR TUBELESS TIRE)

main90942-05009iCDE120,ZZE12#..JPP..WG200110-200405

42611JVALVE (FOR TUBELESS TIRE SPARE)

main90942-05009iNDE120,ZZE12#..JPP200110-200405

42652TIRE

main42652-1A570iZZE121..JPP..SED..4FC..SOL200110-200302

195/60R15,*Y/H,CHINA SPEC

sub42652-1A571

main42652-1A571iZZE121..JPP..SED..4FC..SOL200302-200405

195/60R15,*Y/H,CHINA SPEC

42652ATIRE (FOR SPARE)

main42652-1A570iZZE121..JPP..SED..4FC..SOL200110-200302

195/60R15,*Y/H,CHINA SPEC

sub42652-1A571

main42652-1A571iZZE121..JPP..SED..4FC..SOL200302-200405

195/60R15,*Y/H,CHINA SPEC

7 parts on this diagram · 3 diagrams in section
