Toyota COROLLA LEVIN — HEATING & AIR CONDITIONING - SET

Parts diagram
88820AIR CONDITIONER & ACCESSORY SUB-ASSY, NO.1
main88820-12030i198305-198505
main88820-12031i198505-198701
main88820-12040i198305-198505
W/POWER STEERING
main88820-12041i198505-198701
W/POWER STEERING
main88820-12050i198305-198505
main88820-12051i198505-198606
main88820-12220i198606-198704
main88820-12230i198701-198704
W/POWER STEERING
main88820-12240i198701-198704
88820AAIR CONDITIONER & ACCESSORY SUB-ASSY, NO.2
main88830-12120i198305-198505
main88830-12130i198305-198505
W/POWER STEERING
main88830-12140i198305-198505
main88830-12380i198505-198704
main88830-12390i198505-198704
main88830-12400i198505-198704
W/POWER STEERING
main88830-12550i198505-198704
main88830-12560i198505-198704
W/POWER STEERING
88860ACCESSORY ASSY, AUTOMATIC AIR CONDITIONER
main88860-12010i198305-198505
main88860-12011i198505-198704
main88860-12020i198305-198505
W/POWER STEERING
main88860-12021i198505-198704
W/POWER STEERING
main88860-12030i198305-198505
main88860-12031i198505-198704

3 parts on this diagram · 1 diagram in section

HEATING & AIR CONDITIONING - SET for Toyota COROLLA LEVIN

This section contains 3 genuine Toyota parts for the HEATING & AIR CONDITIONING - SET system of the Toyota COROLLA LEVIN. Key components include: AIR CONDITIONER & ACCESSORY SUB-ASSY, NO.1, AIR CONDITIONER & ACCESSORY SUB-ASSY, NO.2, ACCESSORY ASSY, AUTOMATIC AIR CONDITIONER.
