Toyota COROLLA FX — CAUTION PLATE & NAME PLATE (ENGINE)

Parts diagram

11284PLATE, ENGINE BOLT INFORMATION

main11284-16040i198709-198808

11288PLATE, ENGINE SYSTEM

main11288-88301i198609-198808

11289PLATE, SPARK PLUG CAUTION

main11289-73020i198609-198808

11291PLATE, ENGINE NAME

main11291-16020i198702-198808

main11291-16040i198609-198808

11298PLATE, EMISSION CONTROL INFORMATION

main11298-01032i198702-198709

main11298-01033i198709-198808

main11298-01042i198702-198709

CALIFORNIA SPEC

main11298-01043i198709-198808

CALIFORNIA SPEC

main11298-02010i198609-198709

main11298-02011i198709-198808

main11298-02020i198609-198709

CALIFORNIA SPEC

main11298-02021i198709-198808

CALIFORNIA SPEC

16481PLATE, RADIATOR RESERVE TANK CAUTION

main16481-01010i198609-198808

17700DPLATE, ENGINE CAUTION

main11293-16060i198609-198709

main17791-02010i198709-198808

17792PLATE, ENGINE VACUUM HOSE INFORMATION

main17792-01043i198709-198808

main17792-01053i198709-198808

CALIFORNIA SPEC

main17792-01063i198709-198808

CALIFORNIA SPEC,W/PS

main17792-01080i198702-198808

main17792-01090i198702-198808

CALIFORNIA SPEC

main17792-01100i198702-198808

CALIFORNIA SPEC,W/PS

main17792-02010i198609-198709

main17792-02011i198709-198808

main17792-16102i198702-198709

main17792-16112i198702-198709

CALIFORNIA SPEC,W/PS

8 parts on this diagram · 1 diagram in section
