Toyota COROLLA CROSS — FRONT FENDER APRON & DASH PANEL
16561CSEAL, RADIATOR TO SUPPORT, NO.1
16592AGUIDE, RADIATOR AIR, NO.3
16594AGUIDE, RADIATOR AIR, NO.2
53028SUPPORT SUB-ASSY, RADIATOR, LOWER
53187ASTAY, RADIATOR SUPPORT, RH
53188BSTAY, RADIATOR SUPPORT, LH
53201SUPPORT SUB-ASSY, RADIATOR
53202SUPPORT SUB-ASSY, RADIATOR, RH
53203SUPPORT SUB-ASSY, RADIATOR, LH
53205SUPPORT SUB-ASSY, RADIATOR, UPPER
53208ASUPPORT SUB-ASSY, HOOD LOCK
53273FBRACKET, FRONT BUMPER RETAINER MOUNTING, RH
53274FBRACKET, FRONT BUMPER RETAINER MOUNTING, LH
53301GCUSHION, HOOD BUMPER
(L)
(J)
53701APRON SUB-ASSY, FRONT FENDER, RH
53702APRON SUB-ASSY, FRONT FENDER, LH
53707EAPRON SUB-ASSY, FENDER SIDE, RH
53708DAPRON SUB-ASSY, FENDER SIDE, LH
53731DMEMBER, FRONT APRON TO COWL SIDE, UPPER RH
53732DMEMBER, FRONT APRON TO COWL SIDE, UPPER LH
53733JMEMBER, FRONT APRON TO COWL SIDE, OUTER FRONT RH
53734GMEMBER, FRONT APRON TO COWL SIDE, OUTER FRONT LH
53742PLATE, FRONT FENDER APRON WIND GUIDE, LH
53746REINFORCEMENT, FRONT FENDER APRON, REAR LH
53814CEXTENSION, FRONT FENDER, LH
53835HBRACE, FRONT FENDER TO EXTENSION, RH
53836GBRACE, FRONT FENDER TO EXTENSION, LH
8718HEATING & AIR CONDITIONING - COOLER PIPING
9008010342
main90080-10342
9008010343
main90080-10343
9010506137
main90105-06137
9010906328
main90109-06328
9010906400
main90109-06400
9010908307
main90109-08307
90109A0060
main90109-A0060
90119A0461
main90119-A0461
9018906237
main90189-06237
9046707214
main90467-07214
91635A0616
main91635-A0616
39 parts on this diagram · 3 diagrams in section
FRONT FENDER APRON & DASH PANEL for Toyota COROLLA CROSS
This section contains 62 genuine Toyota parts for the FRONT FENDER APRON & DASH PANEL system of the Toyota COROLLA CROSS. Key components include: SEAL, RADIATOR TO SUPPORT, NO.1, GUIDE, RADIATOR AIR, NO.3, GUIDE, RADIATOR AIR, NO.2, SUPPORT SUB-ASSY, RADIATOR, LOWER, STAY, RADIATOR SUPPORT, RH.
