Toyota COROLLA COUPE — CAUTION PLATE & NAME PLATE (ENGINE)

11275PLATE, IGNITION TIMING ADJUSTING CAUTION

main11275-16010i198502-198505

main11275-16011i198505-198608

11278PLATE, ENGINE EMISSION IDENTIFICATION

main11278-16020i198505-198704

SINGAPORE SPEC

11288PLATE, ENGINE SYSTEM

main11288-88301i198308-198707

T-VIS

11289PLATE, SPARK PLUG CAUTION

main11289-13040i198505-198606

main11289-13040i198504-198505

FRG SPEC

main11289-73020i198606-198704

11291PLATE, ENGINE NAME

main11291-16020i198305-198612

main11291-16021i198612-198704

main11291-16040i198308-198707

4A-GE

11298PLATE, EMISSION CONTROL INFORMATION

main11298-16040i198305-198505

main11298-16050i198504-198505

FRG SPEC

main11298-16051i198510-198607

main11298-16052i198608-198704

main11298-16080i198308-198311

main11298-16081i198311-198502

main11298-16230i198502-198608

main11298-16320i198505-198510

main11298-16320i198504-198505

FRG SPEC

main11298-16430i198607-198608

17700DPLATE, ENGINE CAUTION

main11293-14030i198305-198704

main11293-16030i198308-198704

17792PLATE, ENGINE VACUUM HOSE INFORMATION

main17792-12030i198504-198505

FRG SPEC

main17792-12030i198505-198508

main17792-12031i198508-198704

main17792-12040i198502-198608

main17792-16020i198305-198505

8 parts on this diagram · 1 diagram in section

CAUTION PLATE & NAME PLATE (ENGINE) for Toyota COROLLA COUPE

This section contains 8 genuine Toyota parts for the CAUTION PLATE & NAME PLATE (ENGINE) system of the Toyota COROLLA COUPE. Key components include: PLATE, IGNITION TIMING ADJUSTING CAUTION, PLATE, ENGINE EMISSION IDENTIFICATION, PLATE, ENGINE SYSTEM, PLATE, SPARK PLUG CAUTION, PLATE, ENGINE NAME.
