Toyota COASTER — SWITCH & RELAY & COMPUTER

0001 1ENGINE & TRANSMISSION 0002 1ENGINE & TRANSMISSION 0003 1ENGINE & TRANSMISSION 0004 1ENGINE & TRANSMISSION 0005 1ENGINE & TRANSMISSION 0006 1ENGINE & TRANSMISSION 0007 1ENGINE & TRANSMISSION 1/2 (EU0008 1ENGINE & TRANSMISSION 2/2 (EU0009 1ENGINE & TRANSMISSION 1/2 0010 1ENGINE & TRANSMISSION 2/2 0011 1TRANSMISSION VALVE BODY 0012 1TRANSMISSION VALVE BODY 0013 1ENGINE ROOM RELAY BLOCK 0014 1ENGINE ROOM RELAY BLOCK 0015 1ENGINE ROOM RERAY BLOCK 0016 1ENGINE ROOM 0017 1COWL 0018 1COWL 0019 1INSTRUMENT PANEL 0020 1INSTRUMENT PANEL 0021 1STEERING 0022 1DOOR 0023 1DOOR 0024 1ROOF & FLOOR 0025 1ROOF & FLOOR 0026 1BACK DOOR

83181GSENSOR, SPEEDOMETER

main83181-36010iBZB60201701-202412

main83181-36010iHZB60,70,TRB70..GEN201701-202201

ABS-WITH(ABS & VSC)

main83181-36010iHZB70..23S..WOC202201-202312

ABS-WITH

main83181-36020iXZB70,80..4FC201701-202012

main83181-36030iXZB70..(23S,25S,30S)..STD..GEN201701-202101

main83181-36030iXZB70..LHD..(23S,29S)..WC..GEN201701-202201

ABS-WITH(ABS & VSC)

main83181-36030iXZB70..LHD..(23S,29S)..WC..GEN202201

ABS-WITH

83181HRING, O (FOR SPEEDOMETER SENSOR)

main90301-18004iBZB60201701-202412

main90301-18004iHZB60,70,TRB70..GEN201701-202201

ABS-WITH(ABS & VSC)

main90301-18004iHZB70..23S..WOC202201-202312

ABS-WITH

83420GAGE ASSY, WATER TEMPERATURE SENDER

main83420-16040iBZB60201701-202412

mainS834201250iXZB70..RHD..23S..GEN201701-202512

83530SWITCH ASSY, OIL PRESSURE (FOR ENGINE)

main83530-28010iBZB60201701-202512

DENSO

main83530-28020iTRB60..GEN201701-202412

DENSO

main83530-28030iHZB70..23S..GCC201701-202412

main83530-60010iGDB70..DX..ARL;GDB70..RHD..(EX,STD)..(ARL,GEN)201701-202512

YAZAKI

main83530-60020iTRB60,70..6F;TRB70..WC..GEN201701-202412

YAZAKI

main83530-E0220iXZB60..GCC201701-201909

sub83530-E0250

main83530-E0250iXZB80;XZB70..20S..5F201909-202512

84210SWITCH ASSY, BACK-UP LAMP

main84210-52050iHZB70..23S..WOC;XZB70..RHD..23S..GEN201701-202512

main84210-60040iTRB60,70..6F202501

84540SWITCH ASSY, NEUTRAL START

main84540-36120iGDB60;GDB70..(02S,19S,22S,23S)..(GCC,GEN,SA,TAIW)202201-202512

main84540-37050iXZB80..6FC201908-202512

main84540-65010iXZB70,80..4FC201701-202012

84540CSWITCH ASSY, NEUTRAL (FOR EXHAUST BRAKE)

main84540-36100iXZB60201701-202512

89491SENSOR, ENGINE OIL LEVEL

main89491-26190iGDB70..BTN202201-202512

main89491-36071iBB60201701-202012

main89491-36110iTRB70..WOC201701-202412

main89491-60060iHZB70..23S..WOC201701-202412

mainS834601580iXZB60..GCC201701-202512

89491AGASKET, ENGINE OIL LEVEL SENSOR

main89493-60010iTRB60,70..6F;HZB70..WC..GEN;HZB70..30S..WOC;HZB60,TRB70..26S,30S201701-202412

main90430-27001iBB60201701-202012

8271136080WIRE, FUSE TO FUSE(FOR COMBUSTION HEATER)

main82711-36080

9043018008

main90430-18008

9165160614

main91651-60614

12 parts on this diagram · 26 diagrams in section
