Toyota CELICA — CAUTION PLATE & NAME PLATE (ENGINE)

Parts diagram

11285PLATE, COOLANT SYSTEM CAUTION

main11285-22030i199908-200507

11289ALABEL, SPARK PLUG NOTICE

main11289-50010i199908-200507

11296ALABEL, ENGINE SERVICE INFORMATION

main11296-27020i200310-200507

11298PLATE, EMISSION CONTROL INFORMATION

main11298-22050i199908-200008

main11298-22080i199908-200008

main11298-22081i200008-200108

main11298-22082i200108-200208

main11298-22083i200208-200308

main11298-22084i200308-200408

main11298-22085i200408-200507

main11298-22090i200008-200108

main11298-22091i200108-200208

main11298-22092i200208-200308

main11298-22140i200408-200507

main11298-22191i200308-200408

main11298-22210i200308-200408

main11298-22211i200408-200507

16701GLABEL, CAUTION

main88723-20081i199908-200507

17792PLATE, ENGINE VACUUM HOSE INFORMATION

main17792-22020i199908-200108

main17792-22021i200108-200308

main17792-22022i200308-200507

main17792-22030i199908-200108

main17792-22031i200108-200507

6 parts on this diagram · 1 diagram in section

CAUTION PLATE & NAME PLATE (ENGINE) for Toyota CELICA

This section contains 6 genuine Toyota parts for the CAUTION PLATE & NAME PLATE (ENGINE) system of the Toyota CELICA. Key components include: PLATE, COOLANT SYSTEM CAUTION, LABEL, SPARK PLUG NOTICE, LABEL, ENGINE SERVICE INFORMATION, PLATE, EMISSION CONTROL INFORMATION, LABEL, CAUTION.
