Toyota CELICA — CAUTION PLATE & NAME PLATE (ENGINE)

Parts diagram
11284PLATE, ENGINE BOLT INFORMATION
main11284-15010i199201-199309
main11284-74030i198910-199309
main11284-74040i198909-199201
main11284-74050i199201-199305
11286PLATE, ENGINE SPECIFICATION
main11286-88382i198910-199309
11288PLATE, ENGINE SYSTEM
main11288-74020i198909-199108
main11288-74040i199108-199109
main11288-74041i199305-199309
main11288-88381i198910-199309
11289PLATE, SPARK PLUG CAUTION
main11289-73020i198910-199108
11291PLATE, ENGINE NAME
main11291-15140i198909-199309
main11291-88380i198910-199309
11292PLATE, ENGINE NAME, NO.2
main11292-74060i198909-199108
sub11292-74080
main11292-74120i199108-199109
main11292-74130i199305-199309
11298PLATE, EMISSION CONTROL INFORMATION
main11298-1A080i198909-199008
main11298-1A090i198909-199008
CALIFORNIA SPEC
main11298-1A200i199008-199108
main11298-1A210i199008-199108
CALIFORNIA SPEC
main11298-1A290i199108-199205
main11298-1A291i199205-199309
main11298-1A300i199108-199205
CALIFORNIA SPEC
main11298-1A301i199205-199309
CALIFORNIA SPEC
main11298-74450i198910-199008
main11298-74460i198910-199008
CALIFORNIA SPEC
main11298-74470i198909-199008
main11298-74480i198909-199008
CALIFORNIA SPEC
main11298-74560i199108-199109
main11298-74570i199008-199108
CALIFORNIA SPEC
main11298-74580i199008-199108
main11298-74590i199008-199108
CALIFORNIA SPEC
main11298-74650i199108-199208
main11298-74660i199108-199208
CALIFORNIA SPEC
main11298-74710i199108-199109
main11298-74720i199108-199109
CALIFORNIA SPEC
main11298-74801i199208-199309
main11298-74811i199208-199309
CALIFORNIA SPEC
main11298-74880i199208-199309
main11298-74890i199208-199309
CALIFORNIA SPEC
15369PLATE, ENGINE OIL CAUTION
main15369-74010i198909-199309
17700CPLATE, AIR CLEANER CAUTION (FOR ENGINE MODEL)
main90917-07119i198909-199309
17792PLATE, ENGINE VACUUM HOSE INFORMATION
main17792-16500i198909-199108
main17792-16501i199108-199205
main17792-16502i199205-199309
main17792-74220i198910-199108
main17792-74230i198909-199108
main17792-74240i199108-199109
main17792-74340i199108-199208
main17792-74360i199109-199208
main17792-74391i199208-199309
main17792-74410i199208-199309
1356410010LABEL, TIMING BELT REPLACEMENT INFORMATION
main13564-10010

11 parts on this diagram · 1 diagram in section
