EPC Data

Toyota CELICA — CAUTION PLATE & NAME PLATE (ENGINE)

Parts diagram
11289PLATE, SPARK PLUG CAUTION
main11289-13040i198208-198512
sub11289-73020
11291PLATE, ENGINE NAME
main11291-35010i198108-198308
sub11291-35030
main11291-35020i198208-198408
main11291-35040i198408-198507
11294PLATE, ENGINE CAUTION, NO.2
main11294-34020i198108-198208
11298PLATE, EMISSION CONTROL INFORMATION
main11298-35140i198108-198208
FEDERAL SPEC
main11298-35160i198108-198208
HIGH ALTITUDE SPEC
main11298-35180i198108-198208
CALIFORNIA SPEC
main11298-35200i198108-198208
main11298-35260i198208-198308
main11298-35310i198208-198308
FEDERAL SPEC
main11298-35320i198208-198308
CALIFORNIA SPEC
main11298-35420i198208-198308
FEDERAL SPEC
main11298-35430i198208-198308
CALIFORNIA SPEC
main11298-35440i198208-198308
HIGH ALTITUDE SPEC
main11298-35570i198308-198408
FEDERAL SPEC
main11298-35580i198308-198408
CALIFORNIA SPEC
main11298-35590i198308-198408
main11298-35650i198408-198507
CALIFORNIA SPEC
main11298-35660i198408-198507
main11298-43040i198108-198208
main11298-43050i198108-198208
CALIFORNIA SPEC
main11298-43080i198108-198208
HIGH ALTITUDE SPEC
main11298-43100i198208-198308
main11298-43110i198208-198308
CALIFORNIA SPEC
main11298-43130i198308-198408
CALIFORNIA SPEC
main11298-43140i198308-198408
main11298-43180i198408-198508
main11298-43181i198508-198512
main11298-43190i198408-198508
CALIFORNIA SPEC
main11298-43191i198508-198512
CALIFORNIA SPEC
17627PLATE, AIR PUMP CAUTION, NO.1
main90917-07075i198108-198308
17628PLATE, AIR PUMP CAUTION
main17628-38010i198108-198308
17700DPLATE, ENGINE CAUTION
main11293-28040i198108-198308
main11293-74060i198411-198512
17792PLATE, ENGINE VACUUM HOSE INFORMATION
main17792-35220i198108-198208
main17792-35230i198108-198208
CALIFORNIA SPEC
main17792-35240i198108-198208
HIGH ALTITUDE SPEC
main17792-35250i198108-198202
main17792-35251i198202-198208
main17792-35270i198208-198308
CALIFORNIA SPEC
main17792-35280i198208-198308
CALIFORNIA SPEC
main17792-35340i198208-198308
main17792-35350i198208-198308
CALIFORNIA SPEC
main17792-35360i198208-198308
HIGH ALTITUDE SPEC
main17792-35460i198308-198408
main17792-35470i198308-198408
CALIFORNIA SPEC
main17792-35480i198308-198408
CALIFORNIA SPEC
main17792-35540i198408-198507
CALIFORNIA SPEC
main17792-35550i198408-198507
CALIFORNIA SPEC
main17792-35560i198408-198507
main17792-43040i198108-198208
main17792-43080i198208-198308
main17792-43120i198308-198408
main17792-43140i198408-198512

8 parts on this diagram · 1 diagram in section
