Toyota CELICA — DISTRIBUTOR

0001 1 0002 1

19100DISTRIBUTOR ASSY

main19050-74040i3SFE,5SFE..ST202,204199311

main19100-88460i3SGTE..ST205199402

19101CAP SUB-ASSY, DISTRIBUTOR

main19101-74180i3SFE,5SFE..ST202,204199311

main19101-88460i3SGTE..ST205199402

19102ROTOR SUB-ASSY, DISTRIBUTOR

main19102-11031i3SFE,5SFE..ST202,204199311

sub19102-11370

main19102-74040i3SGTE..ST205199402

19107ARING, O, DISTRIBUTOR HOUSING

main90099-14090i3SGTE..ST205199402

main90099-14091i3SFE,5SFE..ST202,204199311-199409

main90099-14127i3SFE,5SFE..ST202,204199409

19115PIECE, DISTRIBUTOR CAP, CENTER

main19115-63010×2i3SFE,5SFE..ST202,204199311

main19115-88280i3SGTE..ST205199402

19121COVER, DUST PROOF

main19121-11080i3SFE,5SFE..ST202,204199311

19127PACKING, DUST PROOF

main19127-74040i3SGTE..ST205199402

main19127-74050i3SFE,5SFE..ST202,204199311

19133CONDENSER, DISTRIBUTOR

main19133-16240i3SFE,5SFE..ST202,204199311

19144LEAD, DISTRIBUTOR BREAKER

main19144-74100i3SFE,5SFE..ST202,204199311

19235HOUSING, DISTRIBUTOR

main19235-74210i3SFE,5SFE..ST202,204199311

main19235-88040i3SGTE..ST205199402

19500BCOIL ASSY, IGNITION

main90919-02163i3SFE,5SFE..ST202,204199311

9009900957

main90099-00957

9009900966

main90099-00966

9009904374

main90099-04374

9009905179

main90099-05179

9011908937

main90119-08937

16 parts on this diagram · 2 diagrams in section
